Airtac F-RMS Axial Mounting Bracket Assembly F-RMS32LB
AirTAC F-RMS32LB Axial Mounting Bracket Complete Kit Specifications
- Model: F-RMS32LB
- Type: Precision axial alignment support bracket kit
- Material: Aluminum alloy (A6063-T5) with black anodized finish
- Bore diameter compatibility: Ø32mm shafts
- Max load capacity: 2,200N radial / 1,500N axial
- Mounting hole pattern: 60mm × 60mm square (M6 threaded holes)
- Surface hardness: HV 400±20
- Weight: 1.18kg (including all mounting hardware)
- Dimensions: 128mm(L) × 82mm(W) × 54mm(H)
- Operating temperature: -30℃ to 120℃
- Vibration resistance: 5-2000Hz, 10G max
- Corrosion resistance: 96hr salt spray test passed
- Included components: Bracket body, shaft collar (x2), set screws (x4), hex key
Heavy-duty axial stabilization solution for precision linear motion systems. Features dual-bearing contact surfaces and military-grade anodization for wear resistance. The integrated shaft collars prevent axial displacement while maintaining 0.02mm concentricity tolerance. Pre-installed thread locker on set screws ensures vibration-resistant fixation.
- Industrial robot arm joint stabilization
- CNC machine lead screw support
- Automated conveyor roller alignment
- 3D printer Z-axis reinforcement
- Medical imaging equipment guide rail systems
Installation protocol:
Apply 0.5-0.8N·m torque using calibrated torque wrench during set screw tightening.
Lubricate shaft contact area with lithium-based grease (NLGI #2) before assembly.
Perform concentricity verification with dial indicator post-installation.
| Property | Property Value |
|---|---|
| sku | F-RMS32LB |
| Bore Diameter | <32 mm> |
