Airtac F-RMS Axial Mounting Bracket Assembly F-RMS40LB
AirTAC F-RMS40LB Axial Fixing Bracket Complete Package Specifications
- Model: F-RMS40LB
- Type: Linear guide rail axial mounting bracket (pre-assembled)
- Compatible rail width: 40mm
- Material: Aluminum alloy ADC12
- Surface treatment: Hard anodized (25μm thickness)
- Mounting hole spacing: 60±0.1mm (longitudinal), 32±0.1mm (transverse)
- Fastener grade: Class 12.9 alloy steel bolts
- Preload torque: 3.5-4.0 N·m (recommended installation torque)
- Static load capacity: 850N (per bracket assembly)
- Dynamic load capacity: 420N (per bracket assembly)
- Operating temperature: -20℃ to 100℃
- Vibration resistance: 5-2000Hz, 30m/s² max
- Weight: 0.52kg ±2% (including fasteners)
- Dimensions: 148mm(L) × 40mm(W) × 38mm(H)
- Included components: Bracket body (x1), M6x12 hex socket screws (x4), Dowel pins (x2), Anti-vibration washers (x4)
Precision-machined axial fixation solution for linear motion systems, featuring dual-dowel pin alignment technology for micron-level positioning accuracy. The integrated design eliminates secondary assembly errors, with 360° force-distributed clamping structure that maintains rail parallelism within 0.01mm/m. Includes corrosion-resistant hardware kit for immediate installation.
- High-speed CNC gantry axis stabilization
- Semiconductor wafer handling robots
- Laser cutting machine linear guide retention
- Automated warehouse shuttle rail systems
- Medical imaging equipment sliding mechanisms
Installation protocol:
Apply 2.5Nm pre-torque during initial alignment, then final torque in cross pattern.
Clean rail mounting surfaces with IPA (isopropyl alcohol) prior to assembly.
Thermal expansion compensation required for installations exceeding 2m rail length.
| Property | Property Value |
|---|---|
| sku | F-RMS40LB |
| Bore Diameter | <40mm> |
