Airtac F-RMSF Axial Fixing Bracket Assembly Kit F-RMSF25LB
AirTAC F-RMSF25LB Axial Fixation Bracket Complete Package Specifications
- Model: F-RMSF25LB
- Type: Linear motion axial fixation kit with pre-assembled components
- Shaft diameter compatibility: 15-25mm
- Material: Aluminum alloy 6061-T6 (anodized finish)
- Mounting style: Dual clamp-type with anti-rotation design
- Load capacity: Static 2,500N / Dynamic 1,200N
- Surface hardness: HV 120±5
- Fastener grade: Class 12.9 hex socket head cap screws
- Temperature range: -40℃ to 120℃
- Vibration resistance: 5-2000Hz, 15G acceleration
- Weight: 820g ±2% (complete set)
- Dimensions: 98mm(L) × 62mm(W) × 34mm(H)
- Accessories included: Mounting bolts (M6×16mm×4), alignment shims (0.1/0.2mm), thread locker
Precision-engineered axial retention system featuring dual-force clamping technology for zero-backlash performance in high-cycle applications. The diamond-textured clamping surface prevents shaft slippage under extreme vibration. Includes vibration-resistant thread locker pre-applied to Grade 12.9 fasteners.
- Industrial robot joint axis stabilization
- CNC machine lead screw end support
- Automated conveyor roller shaft fixation
- 3D printer Z-axis reinforcement
- Medical imaging equipment guide rail systems
Installation protocol:
Torque mounting bolts to 8.8-10.6N·m in cross pattern sequence.
Use included shims to achieve ≤0.02mm radial runout.
Re-torque after 50 operating hours.
| Property | Property Value |
|---|---|
| sku | F-RMSF25LB |
| Bore Diameter | <25 mm> |
