Airtac F-RMSF Axial Fixing Bracket Assembly Kit F-RMSF32LB
AirTAC F-RMSF32LB Axial Mounting Bracket Kit Specifications
- Model: F-RMSF32LB
- Type: Pre-assembled axial mounting bracket kit
- Material: Anodized aluminum alloy (AL6063-T5)
- Axial load capacity: 1,500N (static), 800N (dynamic)
- Radial load capacity: 300N (static), 150N (dynamic)
- Mounting hole pattern: 32mm × 32mm square configuration
- Bolt specifications: M6 × 1.0 pitch (Class 8.8 included)
- Surface hardness: HV 120-150
- Weight: 1.2kg ±5%
- Dimensions: 100mm(L) × 80mm(W) × 45mm(H)
- Operating temperature: -20℃ to 120℃
- Surface treatment: Sandblasting + Clear anodization
- Parallelism tolerance: ≤0.02mm/m
- Flatness tolerance: ≤0.05mm
- Included components: Bracket body, pre-installed guide blocks, mounting bolts (4 pcs), anti-vibration washers (4 pcs)
Precision-engineered axial alignment solution designed for linear motion systems requiring micron-level positioning accuracy. Features dual-stage hardening treatment on load-bearing surfaces and integrated vibration dampening through multi-layer composite washers. The pre-lubricated guide channels reduce break-in period by 60% compared to standard brackets.
- High-speed linear modules in SMT assembly lines
- Multi-axis robotic arm end-effector mounting
- Precision grinding machine tool slides
- Semiconductor wafer handling robots
- Automated optical inspection (AOI) equipment
Installation protocol:
Use torque-controlled wrench (recommended 8-10Nm) for bolt tightening in cross pattern sequence.
Perform laser alignment verification after installation. Avoid overtightening - maximum deformation allowance 0.003mm.
| Property | Property Value |
|---|---|
| sku | F-RMSF32LB |
| Bore Diameter | <32 mm> |
