Airtac F-SC-CA Single Lug Bracket Assembly F-SC250CA
AirTAC F-SC-CA Single Ear Bracket Finished Kit F-SC250CA Technical Details
- Model: F-SC250CA
- Type: Pre-assembled single ear mounting bracket kit
- Material: Aluminum alloy ADC12
- Surface treatment: Black anodized
- Mounting hole size: M8×1.25 (customizable for M6/M10)
- Compatible cylinder series: SC standard cylinders (SC32~SC100)
- Max dynamic load capacity: 30kg (with safety factor 3)
- Max static load capacity: 60kg
- Weight: ~850g
- Dimensions: 250mm(L) × 50mm(W) × 40mm(H)
- Operating temperature: -20℃ to 80℃
- Vibration resistance: ≤49 m/s² (10-150Hz)
- Corrosion resistance: 96hr salt spray test passed
Heavy-duty bracket kit with pre-installed mounting hardware, featuring precision-machined alignment grooves and reinforced rib design. Includes 4x M8×25 flange bolts, 8x anti-vibration washers, and 4x self-locking nuts pre-assembled for immediate installation. Compatible with ISO 15552 cylinder standards.
- Industrial robot end-of-arm tooling mounts
- Pneumatic cylinder stabilization in packaging machinery
- Linear actuator support in automated assembly lines
- Vibration-sensitive measurement equipment mounting
- Material handling system guide rail supports
Installation guidelines:
Use 8-10Nm torque for M8 fasteners. Apply thread-locking compound on bolts when used in high-vibration environments.
Align cylinder axis within ±0.5° angular tolerance.
Avoid galvanic corrosion - do not directly contact with stainless steel components without insulation washers.
| Property | Property Value |
|---|---|
| sku | F-SC250CA |
