Airtac F-SC-CB Double Ear Fixed Bracket Complete Assembly Package F-SC200CB
$120.94
Regular price
$128.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SC200CB
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AIRTAC
Series: F-SC-CB Double Ear Type Fixed Bracket Assembly Kit
Professional Description:
F-SC-CB series represents a precision-engineered cylinder mounting solution featuring dual clevis ear design with pre-assembled hardware. This complete bracket assembly ensures secure pneumatic cylinder fixation, providing axial stability and vibration resistance in industrial automation systems. Compatible with standard ISO cylinder profiles, the kit includes corrosion-resistant fasteners and alignment shims for simplified installation.
Installation protocol:
Use torque-controlled wrench (recommended 8-10Nm) for M6 fasteners.
Apply thread-locking compound to prevent vibration-induced loosening.
Compatible with AirTAC SC series guides (SC20/SC25/SC30).
AirTAC F-SC-CB Double Ear Bracket Kit F-SC200CB Technical Details
- Model: F-SC200CB (Complete Bracket Kit)
- Type: Pre-assembled dual mounting bracket
- Material: Stainless steel base + aluminum alloy ears
- Max Load Capacity: 180 kg static / 90 kg dynamic
- Mounting Hole Pattern: 160mm × 40mm (horizontal × vertical)
- Surface Treatment: Nickel-plated (anti-corrosion)
- Operating Temp Range: -40℃ to 150℃
- Weight: 0.65 kg (complete assembly)
- Dimensions: 200mm(L) × 50mm(W) × 25mm(H)
- Thread Specifications: M6×1.0 mounting threads (4 positions)
- Vibration Resistance: ≤5G @ 10-2000Hz
- Wear Resistance: ≥500,000 cycles @ 50kg load
Heavy-duty modular bracket system with pre-installed alignment pins and wear-resistant bushings. Features asymmetrical ear design for multi-angle component mounting (adjustable ±15°). Includes vibration-damping rubber pads (3mm thickness) and stainless steel fasteners as standard.
Primary Applications:
- Linear guide rail end support mounting
- Pneumatic cylinder pivot point reinforcement
- Conveyor system structural joints
- Robotic end-effector adapter plates
- Precision stage equipment frameworks
Installation protocol:
Use torque-controlled wrench (recommended 8-10Nm) for M6 fasteners.
Apply thread-locking compound to prevent vibration-induced loosening.
Compatible with AirTAC SC series guides (SC20/SC25/SC30).
| Property | Property Value |
|---|---|
| sku | F-SC200CB |
