Airtac F-SC-CB Double Ear Fixed Bracket Complete Assembly Package F-SC250CB
AirTAC F-SC-CB Double Ear Fixed Bracket Kit F-SC250CB Technical Details
- Model: F-SC250CB (Complete Bracket Kit)
- Material: Aluminum alloy ADC12
- Surface treatment: Black anodized oxidation
- Mounting hole spacing: 250±0.2mm (center-to-center)
- Compatible cylinder series: SC32/SC50/SC80/SC100/SC125/SC160/SC200/SC250
- Maximum static load capacity: 2,500N (vertical direction)
- Maximum dynamic load: 1,800N @ ≤0.5m/s
- Operating temperature: -20℃ to +80℃
- Corrosion resistance: 500hr salt spray test passed
- Weight: 2.85kg ±3%
- Dimensions: 310mm(L) × 68mm(W) × 42mm(H)
- Mounting screw specification: M8×1.25 (4 places)
- Parallelism tolerance: ≤0.15mm/m
- Surface hardness: HV 120±15
Heavy-duty dual mounting bracket engineered for high-moment applications in linear motion systems. Features precision-machined alignment surfaces and through-hardened inserts for repeated assembly/disassembly. Includes pre-installed vibration-resistant flange nuts and alignment dowels (ISO 8734 standard). Compatible with ISO 15552 pneumatic cylinders.
- Palletizing robot base frame reinforcement
- CNC machine tool slide unit stabilization
- Automotive welding fixture structural support
- Plastic injection molding machine ejector mechanisms
- Semiconductor wafer handling equipment
Installation protocol:
Apply 25-30N·m torque using crisscross pattern during bolt tightening.
Use Shim Kit F-SCK5 when mounting on surfaces with flatness >0.2mm/m.
Lubricate guide pins with ISO VG32 hydraulic oil before assembly.
| Property | Property Value |
|---|---|
| sku | F-SC250CB |
