Airtac F-SC-LB Axial Fixing Bracket Finished Product Package F-SC125LB
$44.16
Regular price
$51.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SC125LB
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description:
Category: Cylinder Accessories
Brand: AirTAC
Series: F-SC-LB Axial Fixing Mount Complete Kit
The F-SC-LB series represents a precision-engineered axial fixing mount assembly designed for secure cylinder installation and alignment stabilization. This complete mounting kit incorporates hardened mounting brackets and pre-assembled fastening components, ensuring optimal axial load distribution and vibration dampening in pneumatic systems. Features corrosion-resistant treated surfaces and standardized interface dimensions for seamless integration with AirTAC ISO-compliant cylinder series. Ideal for applications requiring precise linear motion control and enhanced structural rigidity in industrial automation setups.
Mounting protocol:
Use 0.02mm feeler gauge to verify parallel alignment during installation.
Apply LOCTITE 243 to fastener threads and torque in cross pattern.
Re-lubricate every 500km of linear travel or 6 months.
Brand: AirTAC
Series: F-SC-LB Axial Fixing Mount Complete Kit
The F-SC-LB series represents a precision-engineered axial fixing mount assembly designed for secure cylinder installation and alignment stabilization. This complete mounting kit incorporates hardened mounting brackets and pre-assembled fastening components, ensuring optimal axial load distribution and vibration dampening in pneumatic systems. Features corrosion-resistant treated surfaces and standardized interface dimensions for seamless integration with AirTAC ISO-compliant cylinder series. Ideal for applications requiring precise linear motion control and enhanced structural rigidity in industrial automation setups.
AirTAC F-SC-LB Axial Fixing Bracket Kit F-SC125LB Technical Details
- Model: F-SC125LB (Complete Kit)
- Type: Linear shaft support bracket with pre-mounted bearings
- Material: Aluminum alloy ADC12 (anodized surface)
- Shaft compatibility: Ø12mm linear shafts
- Mounting hole spacing: 50mm ±0.02mm (center-to-center)
- Bearing type: Pre-lubricated bronze bushings (2 per unit)
- Static load capacity: 1,200N radial / 800N axial
- Dynamic load rating: 750N radial / 500N axial
- Mounting torque: 1.5-2.0N·m (M5 fasteners)
- Surface hardness: HV 120±15
- Weight: 480g ±10g
- Dimensions: 78mm(L) × 62mm(W) × 42mm(H)
- Operating temp: -30℃ to 120℃ (no sudden temp changes)
- Corrosion resistance: 96hr salt spray test passed
Precision-machined dual-bearing support kit for linear motion systems, featuring vibration-damped design with integrated dust seals. Includes mounting hardware and alignment shims for rapid installation. Compatible with ISO 10285 standard shafts.
Common Implementations:
- CNC tool carriage stabilization systems
- 3D printer gantry axis reinforcement
- Automated conveyor roller supports
- Medical imaging equipment slides
- Robotic arm pivot point reinforcement
Mounting protocol:
Use 0.02mm feeler gauge to verify parallel alignment during installation.
Apply LOCTITE 243 to fastener threads and torque in cross pattern.
Re-lubricate every 500km of linear travel or 6 months.
