Airtac F-SC-LB Axial Fixing Bracket Finished Product Package F-SC250LB
Brand: AirTAC
Series: F-SC-LB Axial Fixing Mount Complete Kit
The F-SC-LB series represents a precision-engineered axial fixing mount assembly designed for secure cylinder installation and alignment stabilization. This complete mounting kit incorporates hardened mounting brackets and pre-assembled fastening components, ensuring optimal axial load distribution and vibration dampening in pneumatic systems. Features corrosion-resistant treated surfaces and standardized interface dimensions for seamless integration with AirTAC ISO-compliant cylinder series. Ideal for applications requiring precise linear motion control and enhanced structural rigidity in industrial automation setups.
AirTAC F-SC-LB Axial Fixation Bracket Kit F-SC250LB Technical Details
- Complete Model: F-SC250LB (Includes pre-assembled components)
- Series: F-SC-LB heavy-duty linear rail system
- Material: Aluminum alloy ADC12 with anti-corrosion treatment
- Max axial load capacity: 18,000N (static)/12,000N (dynamic)
- Mounting hole pattern: 250mm × 55mm rectangular array
- Temperature tolerance: -30℃ to 120℃ (with optional high-temp seals)
- Surface finish: Hard anodized (25μm thickness)
- Compatible rail type: HGH/EGH/SHS series linear guides
- Mounting bolt specification: M8×1.25 grade 12.9 (included)
- Repeat positioning accuracy: ±0.02mm
- Torque requirements: 22-25N·m for main fasteners
- Weight: 3.85kg (complete kit with hardware)
- Dimensions: 268mm(L) × 72mm(W) × 48mm(H)
- Vibration resistance: 5-2000Hz, 15G acceleration
- Protection rating: IP67 (with optional seal kit)
Precision-machined fixation system engineered for high-load linear motion applications. Features integrated dust channels and thermal expansion compensation slots. Includes pre-loaded wave springs for vibration dampening and anti-backlash adjustment shims. Compatible with automatic lubrication systems through built-in grease ports.
- CNC gantry axis stabilization in machining centers
- Automated warehouse retrieval system guide rails
- Semiconductor wafer handling robot base frames
- High-speed packaging line conveyor supports
- 3D metal printing gantry reinforcement
Installation protocol:
Surface flatness ≤0.05mm/m, use 0.02mm feeler gauge for gap inspection.
Apply medium-strength thread locker (242 grade) on fasteners. Thermal soak
at 40℃ for 2hrs before precision alignment.
