Airtac F-SC Sensor Mounting Bracket Assembly Kit F-SC125SH
AirTAC F-SC125SH Sensor Bracket Kit Technical Details
- Model: F-SC125SH
- Type: Universal inductive sensor mounting kit
- Material: Aluminum alloy (AL6063-T5) with black anodized finish
- Compatible Sensor Diameter: Φ12mm standard (adaptable to 10-14mm with included shims)
- Mounting Orientation: Horizontal/Vertical/45° angular installation
- Fastener Type: M5×20mm stainless steel hex socket screws (x4 included)
- Torque Rating: 1.2-1.5N·m (recommended installation torque)
- Surface Hardness: HV 150±20 (anodized layer)
- Temperature Resistance: -40℃ to +120℃ (continuous operation)
- Vibration Resistance: 10-55Hz, 1.5mm double amplitude
- Weight: 218g ±5g (including all mounting hardware)
- Dimensions: 125mm(L) × 38mm(W) × 28mm(H) (main bracket body)
- Accessories: 4x M5 screws, 8x anti-vibration rubber pads, 2x 0.5mm adjustment shims
- IP Rating: IP67 (when properly installed with included seals)
Professional-grade sensor retention system featuring micro-adjustment capability (±1.5mm lateral shift) for precise photoelectric or proximity sensor alignment. The hardened mounting surface prevents scoring from repeated adjustments, while the integrated cable management channels (3mm routing slots) maintain clean installations.
- Precision position detection in SMT pick-and-place machines
- Automated packaging line object presence verification
- CNC machine tool limit switch mounting
- AGV collision avoidance system installations
- Robotic welding arm end effector alignment
Installation protocol:
Apply thread-locking compound to M5 fasteners when used in high-vibration environments.
Maximum recommended installation cycles: 500 repositions before bushing inspection.
