Airtac F-SC Sensor Mounting Bracket Assembly Kit F-SC32H
AirTAC F-SC32H Sensor Bracket Kit Technical Details
- Model: F-SC32H Complete Package
- Material: Aluminum alloy 6063-T5
- Surface treatment: Anodized (black)
- Sensor compatibility: M8 to M18 cylindrical sensors
- Mounting hole spacing: 32mm standard (configurable to 40/50mm)
- Bracket type: Horizontal clamp with anti-rotation design
- Fastener type: Stainless steel M4 hex socket screws (ISO 4762)
- Torque specification: 0.8-1.2 N·m
- Vibration resistance: ≤10 m/s² (IEC 60068-2-6)
- Temperature range: -25℃ to +80℃
- Weight: 182g ±3g (including hardware)
- Dimensions: 60mm(L) × 32mm(W) × 25mm(H)
- Package contents: Bracket body, 4x M4x8 screws, 4x spring washers, 2x positioning shims
Heavy-duty sensor mounting solution featuring multi-point stress distribution design. The hardened clamping surface prevents sensor slippage while maintaining 0.05mm repeat positioning accuracy. Integrated cable management slots (3mm/5mm/7mm options) compatible with shielded sensor cables.
- Align sensor body with V-shaped locating groove
- Insert shims for height adjustment (0.5mm increments)
- Hand-tighten screws in cross pattern
- Final torque with calibrated driver (1.0 N·m recommended)
- Verify sensor alignment with dial indicator
- CNC machine tool limit detection systems
- Automated guided vehicle (AGV) proximity sensing
- Pharmaceutical packaging line quality control stations
- Lithium battery assembly precision positioning
Maintenance advisory:
Apply lithium-based grease (NLGI #2) to sliding surfaces quarterly in high-humidity environments.
Replace spring washers after 5 installation cycles.
| Property | Property Value |
|---|---|
| sku | F-SC32H |
