Airtac F-SC Sensor Mounting Bracket Assembly Kit F-SC80H
$3.68
Regular price
$11.18
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SC80H
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC F-SC80H Sensor Bracket Kit Technical Details
- Model: F-SC80H
- Type: Universal sensor mounting bracket set
- Material: Aluminum alloy (6063-T5 grade)
- Surface treatment: Black anodized oxidation treatment
- Compatible sensors: SC series proximity sensors (SC50-SC120)
- Mounting options: T-slot clamping or M4 screw fixation
- Rail compatibility: 35mm standard DIN rail (EN 60715)
- Clamping force: 18-22N·m (torque recommended)
- Vibration resistance: ≤10Hz @ 2mm amplitude
- Temperature range: -20℃ to +80℃
- Protection rating: IP67 (sealed against dust/immersion)
- Weight: 350g ±5% (including all hardware)
- Dimensions: 80mm(L) × 40mm(W) × 25mm(H)
Heavy-duty sensor mounting solution with multi-axis adjustability (X/Y/Z ±5mm fine-tuning). Features integrated cable management slots and anti-vibration silicone pads. Pre-assembled kit includes stainless steel M4×16mm hex bolts, spring washers, and T-nut adapters.
Industrial Applications:
- Position detection in CNC machine tooling systems
- Automated conveyor belt alignment monitoring
- Robotic arm end-effector positioning
- Packaging machine safety interlock systems
- AGV collision avoidance sensor mounting
Installation guidance:
Apply thread-locking compound on mounting screws when used in high-vibration environments.
Maintain 0.5-1mm gap between bracket and sensor housing for thermal expansion.
| Property | Property Value |
|---|---|
| sku | F-SC80H |
