Airtac F-SC Sensor Mounting Bracket Assembly Kit F-SC80SH
$4.62
Regular price
$12.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SC80SH
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC F-SC80SH Sensor Mounting Bracket Kit Specifications
- Model: F-SC80SH
- Type: Complete sensor mounting solution with shock absorption
- Material: Aluminum alloy 6063-T5
- Surface treatment: Black anodized (MIL-A-8625 Type II)
- Compatible sensor diameter: Ø80mm (±0.2mm adjustability)
- Mounting options: M6 T-slot bolts (included) or 35mm DIN rail
- Vibration damping: 3-layer silicone pads (Shore A 50±5)
- Weight: 480g ±2% (including all hardware)
- Dimensions: 98mm(L) × 86mm(W) × 32mm(H)
- Operating temperature: -40℃ to 120℃
- IP rating: IP67 when used with compatible sensor
- Torque specification: 1.2-1.5N·m for sensor clamping
Heavy-duty modular mounting system designed for industrial photoelectric/proximity sensors. Features anti-rotation design with 5-axis adjustability (±3° pitch/yaw) and EMI shielding through conductive mounting surfaces. Includes stainless steel hardware with anti-vibration washers.
Typical Applications:
- Robotic end-effector position feedback systems
- High-speed packaging line sensor arrays
- CNC machine tool limit detection
- AGV collision avoidance systems
- Food processing conveyor alignment
Installation protocol:
Apply 0.05mm thick thermal compound (not included) between bracket and machine surface for optimal heat dissipation in continuous operation. Torque sequence: center bolts first, then perimeter fasteners in cross pattern.
Compatible with:
Omron E3Z, Keyence FS-N Series, Sick WT34 Family, and equivalent 80mm cylindrical sensors
| Property | Property Value |
|---|---|
| sku | F-SC80SH |
