Airtac F-SE-CA Single Lug Bracket Assembled Kit F-SE40CA
AirTAC F-SE-CA Single Ear Fixing Bracket Kit F-SE40CA Technical Details
- Model: F-SE40CA
- Type: Standard single ear mounting bracket kit
- Material: Aluminum alloy ADC12
- Surface treatment: Black anodized
- Max Load Capacity: 55kg (static)/35kg (dynamic)
- Mounting hole spacing: 40±0.2mm (center-to-center)
- Hole diameter: Ø5.5mm (through hole)
- Thread specifications: M5×0.8 mounting threads
- Clamping force: 490N (at recommended torque)
- Temperature range: -20℃ to 120℃
- Vibration resistance: ≤10Hz/1.5mm amplitude
- Weight: 0.28kg (including all hardware)
- Dimensions: 42mm(L) × 38mm(W) × 16mm(H)
- Corrosion resistance: 96hr salt spray test passed
- Compatibility: Designed for 40mm series cylinders
Precision-engineered mounting solution for pneumatic cylinder fixation, featuring reinforced rib design for vibration damping. The zinc-plated carbon steel fasteners and anti-loosening washers ensure secure attachment in high-cycle applications. Anodized surface provides scratch resistance and electrical insulation (withstand voltage 500V DC).
- Linear actuator mounting in packaging machinery
- Pneumatic gripper alignment in robotic arms
- Sensor bracket attachment on conveyor systems
- Vacuum cup holder fixation in pick-and-place units
- Support structure for pneumatic slides in automation cells
Mounting guidance:
Apply 2.0-2.5N·m torque using calibrated tool. Use shim washers on uneven surfaces.
Perform torque check after 50 operating cycles. Avoid galvanic corrosion by isolating
from dissimilar metals in humid environments.
| Property | Property Value |
|---|---|
| sku | F-SE40CA |
