Airtac F-SE-CA Single Lug Bracket Assembled Kit F-SE63CA
$12.99
Regular price
$20.49
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SE63CA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AIRTAC
Series: F-SE-CA
**F-SE-CA Single Ear Bracket Complete Assembly Kit**
AIRTAC's F-SE-CA series single ear mounting bracket kit provides a robust and precision-engineered solution for cylinder fixation in pneumatic systems. Designed for seamless integration with standard cylinder models, this complete assembly features a reinforced single-ear structure with pre-drilled mounting holes for quick installation. The zinc-plated steel construction ensures corrosion resistance and extended service life in demanding industrial environments. Compatible with ISO 15552 cylinder profiles, it delivers vibration-dampening stability and precise axial alignment during reciprocating motions. The kit includes all necessary fasteners (DIN 933 hex bolts and DIN 985 lock nuts) for secure mounting, meeting ISO 6431 mounting standards. Ideal for linear motion applications requiring rigid mounting interfaces while maintaining angular adjustment flexibility.
Installation protocol:
Mount perpendicular to cylinder axis using 0.1mm feeler gauge for parallelism check.
Retorque after 50 operational hours. Avoid galvanic corrosion when connecting to
stainless steel components.
AirTAC F-SE-CA Single Ear Bracket Kit F-SE63CA Technical Details
- Model: F-SE63CA (Complete Bracket Assembly)
- Bracket Type: Single-ear fixed mounting bracket
- Material: Aluminum alloy ADC12 (Die-cast construction)
- Surface Treatment: Black electrophoretic coating
- Compatible Cylinder Series: SC/SU/SI 63mm bore size
- Mounting Hole Spacing: 60±0.2mm (Center-to-center)
- Fastener Specifications: M6×20mm hex socket screws (Class 8.8)
- Torque Requirements: 5.5-6.5 N·m (Precision calibrated)
- Weight: 485g ±5g (Including all hardware)
- Dimensions: 78mm(L) × 63mm(W) × 42mm(H)
- Operating Temperature: -20°C to 120°C (Non-lubricated)
- Vibration Resistance: ≤15Hz frequency, 1.5mm amplitude
- Corrosion Resistance: 96hrs salt spray test compliant
Heavy-duty mounting solution for cylinder stabilization, featuring anti-rotation design with precision-machined locating pins. Includes pre-assembled vibration-resistant washers and thread-locking compound applied to fasteners. Compatible with ISO 15552 standard profiles.
Implementation Scenarios:
- Robotic welding arm pivot point reinforcement
- Assembly line lifting cylinder mounting
- Packaging machinery vertical actuator support
- Plastic injection molding machine ejector mechanisms
- Automated warehouse stacker crane installations
Installation protocol:
Mount perpendicular to cylinder axis using 0.1mm feeler gauge for parallelism check.
Retorque after 50 operational hours. Avoid galvanic corrosion when connecting to
stainless steel components.
| Property | Property Value |
|---|---|
| sku | F-SE63CA |
