Airtac F-SE-CB Double Ear Fixed Bracket Assembly F-SE100CB
AirTAC F-SE-CB Double Ear Bracket Kit F-SE100CB Technical Specifications
- Model: F-SE100CB
- Type: Pre-assembled mounting bracket kit
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Anodized (black)
- Compatible cylinder series: SE/SC standard cylinders
- Applicable cylinder bore: Ø100mm
- Mounting hole spacing: 120±0.2mm (horizontal) × 80±0.2mm (vertical)
- Fastener specs: M10×1.5 class 8.8 hex bolts with anti-loosening washers
- Static load capacity: ≤2,500N
- Dynamic load capacity: ≤1,800N (at 0.5MPa)
- Operating temperature: -20℃ to 150℃
- Weight: 2.3kg ±5%
- Dimensions: 120mm(L) × 80mm(W) × 45mm(H)
- Package contents: Bracket body ×1, Mounting bolts ×4, Shim set ×2, Torque guide card ×1
Heavy-duty dual ear mounting solution featuring precision-machined alignment surfaces and vibration-resistant design. The hardened contact surfaces (HRC 45-50) ensure stable cylinder positioning, while the modular shim system allows ±3mm axial adjustment. Includes pre-lubricated fasteners with 12.9μm zinc-nickel coating for harsh environments.
- Vertical mounting of large-bore cylinders in press machinery
- Multi-axis robotic arm joint connections
- Vibration-intensive applications like punching/stamping equipment
- High-cycle automation lines requiring quick cylinder replacement
Mounting protocol:
Apply 45-50N·m torque using calibrated wrench in cross pattern.
Use included 0.5mm shims when mounting on uneven surfaces (>0.2mm/m flatness deviation).
Perform re-torquing after first 50 operating hours.
| Property | Property Value |
|---|---|
| sku | F-SE100CB |
