Airtac F-SE-CB Double Ear Fixed Bracket Assembly F-SE32CB
AirTAC F-SE-CB Double Ear Bracket Kit F-SE32CB Technical Details
- Model: F-SE32CB (Complete Bracket Kit)
- Material: 6063-T5 Aluminum Alloy
- Surface Treatment: Black Anodized (MIL-A-8625 Type II)
- Bolt Hole Size: M6×1.0 Thread
- Mounting Spacing: 32±0.2mm (Center-to-Center)
- Max Load Capacity: 180N Static / 120N Dynamic
- Weight: 220g ±5% (Including Fasteners)
- Dimensions: 75mm(L) × 32mm(W) × 32mm(H)
- Operating Temperature: -40℃ to 120℃
- Vibration Resistance: 10-2000Hz, 15G Max
- Corrosion Resistance: 96hrs Salt Spray Test Pass
- Included Components:
- 2× Bracket Bodies
- 4× M6×20 Stainless Steel Hex Bolts (A2-70)
- 4× M6 Spring Lock Washers
- 4× M6 Flat Washers
Precision-engineered dual mounting solution for cylinder fixation, featuring laser-etched alignment marks and chamfered edges for tool-free installation. The through-hole design allows cable/pipe routing through the bracket body. Compatible with ISO 15552 (formerly DIN/VDMA 24552) standard cylinders.
- Robotic arm joint stabilization in automotive assembly lines
- Vertical actuator mounting for packaging machinery
- Modular fixture systems in semiconductor handling equipment
- Vibration-sensitive applications like optical alignment stages
Installation protocol:
Use torque wrench (recommended 5.6±0.5N·m) for even fastening.
Apply thread locker (LOCTITE 243) if cyclic loading exceeds 50Hz.
Maintain 0.5-1mm gap between bracket and cylinder body for thermal expansion.
| Property | Property Value |
|---|---|
| sku | F-SE32CB |
