Airtac F-SE-CB Double Ear Fixed Bracket Assembly F-SE40CB
AirTAC F-SE-CB Double Ear Bracket Finished Product Package F-SE40CB Specifications
- Model: F-SE40CB
- Type: Double Ear Bracket Kit with Pre-Assembled Hardware
- Material: Aluminum Alloy 6063-T5 (Anodized Surface Treatment)
- Compatible Cylinder Series: MAL/MBL Series 40mm Bore Size
- Mounting Style: Through-Hole Dual Ear Bracket + M6x1.0 Screw Set
- Bracket Hole Diameter: 8.5mm (Slotted Holes for Adjustment)
- Screw Specifications: M6x1.0x25L Stainless Steel (4pcs included)
- Max Torque Capacity: 12 N·m (Recommended Tightening Torque: 8-10 N·m)
- Temperature Range: -20°C to 120°C (Continuous Use)
- Surface Hardness: HV 80-100 (Anodized Layer Thickness 15-20μm)
- Weight: 450g ±5% (Including All Mounting Components)
- Dimensions: 200mm(L) × 40mm(W) × 40mm(H) (Bracket Body Only)
- IP Rating: IP54 (Dust Protected & Splash Resistant)
Heavy-duty alignment bracket kit designed for secure cylinder mounting in vibration-prone environments. Features precision-machined slots for ±3mm positional adjustment and corrosion-resistant anodized finish. Includes pre-installed thread-locking adhesive on fasteners to prevent loosening under dynamic loads.
- Industrial automation robotic arm joints
- Packaging machinery linear actuator mounting
- CNC equipment pneumatic cylinder installations
- Material handling system pivot points
- Semiconductor manufacturing wafer transfer units
Installation protocol:
Apply 0.5-0.8Nm pre-torque during alignment phase before final tightening.
Use spacer shims (not included) if mounting surface flatness exceeds 0.2mm/mm².
Re-torque after 50 operational hours.
| Property | Property Value |
|---|---|
| sku | F-SE40CB |
