Airtac F-SE-TC Center Trunnion Bracket F-SE40TC
AirTAC F-SE-TC Intermediate Trunnion Bracket F-SE40TC Technical Details
- Model: F-SE40TC
- Type: Heavy-duty trunnion mounting bracket
- Material: SUS304 stainless steel (electropolished)
- Static load capacity: 3,500 N (radial), 2,200 N (axial)
- Mounting hole diameter: Φ12.5mm (+0.2/-0 mm tolerance)
- Surface roughness: Ra ≤ 0.8μm (bearing contact areas)
- Hardness: HRC 38-42 (heat-treated surfaces)
- Temperature resistance: -30℃ to 150℃
- Weight: 1.85 kg ±2%
- Dimensions: 118mm(L) × 62mm(W) × 82mm(H)
- Mounting torque: 25-30 N·m (M10 fasteners)
- Corrosion resistance: 500hr salt spray test compliant
Precision-engineered trunnion bracket with dual-bearing support structure, designed for heavy cyclic loading in automated systems. Features hardened contact surfaces and corrosion-resistant construction, compatible with ISO 15552 (DIN/VDMA 24562) standard cylinders. Includes integrated alignment marks for simplified installation.
- Industrial robot arm joint articulation
- Packaging machinery rotary actuators
- Automated material handling systems
- CNC machine tool clamping mechanisms
- Semiconductor wafer handling robots
Installation guidance:
Apply medium-strength thread locker (Loctite 243 recommended) on fasteners.
Perform torque calibration using certified wrench. Maintain 0.02-0.05mm gap
between bracket and cylinder mounting face for thermal expansion.
| Property | Property Value |
|---|---|
| sku | F-SE40TC |
