Airtac F-SG-LB Axial Mounting Bracket Complete Assembly F-SG250LB
AirTAC F-SG-LB Series Axial Mount Bracket Kit - F-SG250LB Detailed Specifications
- Model Code: F-SG250LB (Complete Assembly Kit)
- Bracket Type: Linear Guide Axial Fixed Side Mount
- Material: Aluminum Alloy ADC12 with Hard Anodized Finish
- Compatible Rail Size: 25mm Width Linear Guides (e.g., HGH25CA/HGW25CC series)
- Max Load Capacity: 850kg Static / 320kg Dynamic
- Mounting Hole Pattern: 4×M6×1.0 Threaded Holes (8mm Depth)
- Surface Hardness: HV400±50
- Operating Temp Range: -20℃ to 120℃
- Weight: 3.8kg (Including All Hardware)
- Dimensions: 250mm(L) × 80mm(W) × 60mm(H)
- Precision Grade: P4 Class (≤0.02mm Runout Tolerance)
- Included Components: Main Bracket, Shim Set (0.1/0.2/0.5mm), M6×12 SHCS (4pcs), Anti-Vibration Washers
Heavy-duty alignment bracket system designed for permanent fixation of linear guide carriage ends. Features dual-stage preload adjustment through calibrated shims (0.1-0.8mm total adjustment range) and vibration-damped mounting. Anodized surface resists coolant penetration with Ra0.8μm surface roughness for precise mating.
- High-rigidity CNC machining center X-axis reinforcement
- Automated warehouse stacker crane rail systems
- Semiconductor wafer handling robot base frames
- Plastic injection molding machine ejector unit guides
- Precision optical stage alignment systems
Installation Protocol:
Torque mounting bolts to 8.8N·m in cross pattern sequence. Use dial indicator to verify
parallel alignment within 0.05mm/m. Apply LOCTITE 243 to bolt threads for permanent installations.
| Property | Property Value |
|---|---|
| sku | F-SG250LB |
