Airtac F-SI-CA Single Lug Bracket Assembly Kit F-SI32CA
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SI32CA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AirTAC
Series: F-SI-CA
**Single Lug Mounting Bracket Complete Assembly Kit**
Engineered for robust cylinder stabilization in pneumatic systems, this precision-machined aluminum alloy bracket features an anodized surface treatment for enhanced corrosion resistance. The single-lug design ensures rigid connections while maintaining angular adjustability for versatile installation compatibility.
**Key Specifications**
• Material: Aluminum Alloy (6063-T5)
• Surface Treatment: Anodized
• Mounting Style: Single Ear (Lateral Fixation)
• Load Capacity: Optimized for ISO/VDMA standard cylinder series
• Pre-assembled configuration with standard fasteners included
**Application**
Ideal for linear actuator installations requiring vibration-damped fixation in automation equipment, packaging machinery, and industrial robotics. The complete kit enables rapid deployment with ±2° axial compensation tolerance, ensuring parallel alignment for cylinder rod extensions.
**Compliance**
Manufactured under ISO 9001:2015 quality standards. Compatible with AirTAC SC/SU/SI series cylinders and industrial pneumatic equipment.
*Note: Includes M6 Class 8.8 mounting hardware and anti-loosening washers. Torque specifications: 12-14 N·m.*
Installation protocol:
Apply 24-28Nm torque during bolt tightening. Use parallel shim washers when mounting
on uneven surfaces. Lubricate pivot point with ISO VG32 hydraulic oil monthly.
AirTAC F-SI-CA Single Ear Fixing Bracket Kit F-SI32CA Technical Details
- Model: F-SI32CA (Complete Assembly Kit)
- Compatible Cylinder Series: SI Standard Cylinders
- Mounting Type: Single Ear Swivel Bracket
- Material: Aluminum Alloy ADC12
- Surface Treatment: Anodized (Natural Silver)
- Bolt Hole Diameter: M8×1.25 (Through Hole)
- Mounting Spacing: 32±0.2mm (Standard Cylinder Size 32)
- Rotation Range: ±5° (Axial Adjustment)
- Load Capacity: Max 980N Static Load
- Operating Temperature: -20℃ to 100℃
- Weight: 0.23kg ±5%
- Dimensions: 78mm(L) × 40mm(W) × 32mm(H)
- Included Hardware: M8×25 Hex Socket Screws (Class 8.8), Spring Washers
Precision-machined pivot bracket designed for stable cylinder mounting in dynamic applications. Features anti-corrosion coating and wear-resistant pivot bushings. The swivel design compensates for minor misalignment during reciprocating motion cycles.
Typical Installation Scenarios:
- Automated welding equipment cylinder mounts
- Material handling system pivot joints
- Packaging machinery linear actuator support
- Plastic injection molding machine ejection units
- Robotic arm end-effector linkages
Installation protocol:
Apply 24-28Nm torque during bolt tightening. Use parallel shim washers when mounting
on uneven surfaces. Lubricate pivot point with ISO VG32 hydraulic oil monthly.
| Property | Property Value |
|---|---|
| sku | F-SI32CA |
