Airtac F-SI-CA Single Lug Bracket Assembly Kit F-SI63CA
$12.99
Regular price
$20.49
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SI63CA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AirTAC
Series: F-SI-CA
**Single Lug Mounting Bracket Complete Assembly Kit**
Engineered for robust cylinder stabilization in pneumatic systems, this precision-machined aluminum alloy bracket features an anodized surface treatment for enhanced corrosion resistance. The single-lug design ensures rigid connections while maintaining angular adjustability for versatile installation compatibility.
**Key Specifications**
• Material: Aluminum Alloy (6063-T5)
• Surface Treatment: Anodized
• Mounting Style: Single Ear (Lateral Fixation)
• Load Capacity: Optimized for ISO/VDMA standard cylinder series
• Pre-assembled configuration with standard fasteners included
**Application**
Ideal for linear actuator installations requiring vibration-damped fixation in automation equipment, packaging machinery, and industrial robotics. The complete kit enables rapid deployment with ±2° axial compensation tolerance, ensuring parallel alignment for cylinder rod extensions.
**Compliance**
Manufactured under ISO 9001:2015 quality standards. Compatible with AirTAC SC/SU/SI series cylinders and industrial pneumatic equipment.
*Note: Includes M6 Class 8.8 mounting hardware and anti-loosening washers. Torque specifications: 12-14 N·m.*
Installation protocol:
Apply 2.5-3N·m torque during fastener tightening. Use shim washers
when mounting on profiles thinner than 8mm. Periodic re-torquing
recommended after 500 operational hours.
AirTAC F-SI-CA Single-Ear Fixed Bracket Kit F-SI63CA Technical Details
- Model: F-SI63CA (Complete Kit)
- Type: Single-ear mounting bracket with integrated hardware
- Material: Aluminum alloy AL6063-T5
- Surface treatment: Black anodized (8-12μm thickness)
- Mounting hole diameter: 6.5±0.1mm
- Compatible rail type: ISO 32mm wide profile (Type T)
- Max vertical load capacity: 120kg (static), 80kg (dynamic)
- Torque resistance: ≤35N·m
- Operating temperature: -40℃ to 150℃
- Package weight: 850g ±5% (including all components)
- Bracket dimensions: 76mm(L) × 32mm(W) × 42mm(H)
- Package dimensions: 120mm × 95mm × 45mm
- Fastener specs: M6×25mm stainless steel hex bolts (Class 8.8)
- Anti-vibration design: Integrated rubber dampener (70±5 Shore A)
Heavy-duty mounting solution for pneumatic components, featuring dual-stage anti-loosening mechanism with spring lock washers. The asymmetric ear design allows 15° angular adjustment post-installation. Includes corrosion-resistant hardware kit for immediate installation on ISO-standard machinery profiles.
Primary Applications:
- Pneumatic valve island mounting in CNC machines
- Sensor bracket for robotic arm end effectors
- Vibration-prone environments like injection molding equipment
- Modular assembly systems using aluminum extrusion frames
- Conveyor system component mounting
Installation protocol:
Apply 2.5-3N·m torque during fastener tightening. Use shim washers
when mounting on profiles thinner than 8mm. Periodic re-torquing
recommended after 500 operational hours.
| Property | Property Value |
|---|---|
| sku | F-SI63CA |
