Airtac F-SI-CB Double Lug Bracket Assembly Kit F-SI50CB
AirTAC F-SI-CB Double-Ear Mounting Bracket Kit F-SI50CB Technical Details
- Full model designation: F-SI50CB
- Bracket type: Universal double-ear fixed mount
- Material: Aluminum alloy ADC12 (ISO AlSi10Mg)
- Mounting hole spacing: 50±0.1mm (center-to-center)
- Compatible cylinder series: SC/SU/SD 50mm bore models
- Surface treatment: Hard anodized (25-30μm thickness)
- Fastener specs: M6×20mm stainless steel screws (ISO 4762)
- Vibration resistance: 5-2000Hz, 15G acceleration
- Static load capacity: 200N vertical/150N lateral
- Operating temp range: -40℃ to 120℃
- Weight: 120g ±5% (including hardware)
- Dimensions: 50mm(W) × 25mm(D) × 20mm(H)
- Package contents: Bracket ×1, Screw set ×2, Anti-vibration washer ×4
Precision-engineered mounting solution for cylinder stabilization, featuring dual reinforced ear design with stress-dispersing geometry. The anodized surface provides corrosion resistance in humid environments, while the optimized clamping force distribution prevents cylinder body deformation during high-cycle operations.
- Multi-axis pneumatic actuator installations
- Vibration-prone environments like stamping presses
- Vertical cylinder mounting in automated packaging lines
- High-temperature paint shop automation systems
- Precision alignment applications in semiconductor handling
Mounting protocol:
Apply 4.5-5.5N·m torque using calibrated tool. Perform concentricity
check with 0.05mm dial indicator before final tightening. Replace
anti-vibration washers every 50,000 cycles in continuous operation.
