Airtac F-SI-FA Front Flange Mounting Plate Assembly F-SI160FA
AirTAC F-SI-FA Front Flange Mounting Plate Kit F-SI160FA Technical Details
- Model: F-SI160FA (Complete Kit)
- Type: Precision-machined front flange mounting solution
- Material: 6063-T5 aluminum alloy
- Surface treatment: Hard anodized (25-30μm thickness)
- Mounting hole pattern: ISO 15552 standard compatible
- Compatible cylinder bore: Ø160mm
- Bolt specification: M12×1.75 grade 10.9 hex socket screws
- Mounting hole spacing: 160mm × 160mm (±0.05mm tolerance)
- Temperature resistance: -20°C to 120°C
- Static load capacity: 9,800N (axial), 4,200N (radial)
- Weight: 3.2kg (with all hardware included)
- Dimensions: 210mm(L) × 180mm(W) × 32mm(H)
- Runout tolerance: ≤0.1mm/m
- Vibration resistance: 5-2000Hz, 15G acceleration
Heavy-duty flange plate featuring CNC-machined reference surfaces (Ra 1.6μm finish) for precision cylinder alignment. Includes vibration-resistant Nord-Lock washers and pre-applied Loctite 243 threadlocker on fasteners. The diamond-knurled grip surfaces prevent tool slippage during installation.
- High-moment industrial robotic arm joints
- Vertical press machine cylinder mounting
- Food processing conveyor alignment systems
- Plastic injection molding machine clamps
- Semiconductor wafer handling robots
Installation protocol:
Use 80-100Nm torque wrench with 3-step tightening sequence (30% → 70% → 100% torque).
Apply lithium-based grease on mating surfaces before alignment.
Thermal expansion compensation required when operating above 80°C.
| Property | Property Value |
|---|---|
| sku | F-SI160FA |
