Airtac F-SI-FA Front Flange Mounting Plate Assembly F-SI200FA
AirTAC F-SI-FA Front Flange Mounting Plate Kit F-SI200FA Technical Details
- Model: F-SI200FA (Complete Kit)
- Material: Anodized aluminum alloy 6063-T5
- Mounting pattern: ISO 15552/VDMA 24562 standard
- Bolt hole spacing: 200mm center-to-center
- Thread specification: M8×1.25×12L (4 holes)
- Surface hardness: HV 150-200
- Weight: 1.65kg ±2%
- Dimensions: 248mm(L) × 62mm(W) × 28mm(H)
- Rail compatibility: 20mm wide linear guides
- Surface finish: Sandblasted + clear anodizing (8-12μm)
- Temperature resistance: -40℃ to 120℃
- Load capacity: 2,500N static / 1,800N dynamic
- Corrosion resistance: 500hr salt spray test passed
Heavy-duty front flange mounting solution designed for ISO-standard pneumatic cylinders, featuring precision-machined alignment slots and reinforced rib structure. The integrated T-slot design allows modular accessory attachment while maintaining ±0.05mm positional accuracy. Includes pre-installed Class 12.9 mounting bolts with anti-vibration washers.
- Industrial robot end-effector mounting
- Palletizing machine cylinder fixation
- Automated welding fixture bases
- Semiconductor handling equipment frames
- Food processing conveyor line supports
Installation guidelines:
Use 18-22N·m torque for M8 fasteners. Apply thread-locking compound on clean,
oil-free threads. Align with laser-leveled datum surfaces before final tightening.
- Optimal pairing: SC200 series cylinders
- Recommended rail: HGH20CA linear guide blocks
- Accessory: FA-MG200 modular guard kit (sold separately)
| Property | Property Value |
|---|---|
| sku | F-SI200FA |
