Airtac F-SI-FA Front Flange Mounting Plate Assembly F-SI32FA
$8.34
Regular price
$15.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SI32FA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description:
**Category:** Pneumatic Cylinder Mounting Kits
**Brand:** AirTAC
**Series:** F-SI-FA
A precision-engineered front flange mounting solution designed for seamless integration with ISO-standard pneumatic cylinders. This complete assembly features a robust anodized aluminum alloy construction with CNC-machined mounting surfaces, ensuring dimensional accuracy and vibration resistance. The pre-assembled design simplifies cylinder installation while maintaining strict axial alignment tolerances. Includes grade 12.9 high-tensile steel fasteners and anti-loosening measures for secure mounting in high-cycle industrial applications. Compatible with ISO 6431/15552 cylinder profiles.
**Key Applications:**
• Linear actuator stabilization in automation systems
• Modular pneumatic circuit assembly
• Precision positioning setups requiring minimal deflection
**Technical Highlights:**
- Corrosion-resistant surface treatment (MIL-A-8625 compliant)
- Integrated load-bearing reinforcement ribs
- ±0.05mm bore concentricity tolerance
- Operating temperature range: -20°C to +80°C
Installation Protocol:
Apply 25-35N·m torque during mounting. Use included anti-seize compound
on threads for stainless-steel interfaces. Validate perpendicularity
with 0.02mm/m precision level before final tightening sequence.
AirTAC F-SI-FA Front Flange Mounting Plate Kit (F-SI32FA) Technical Details
- Model: F-SI32FA (Complete Kit)
- Type: Front flange mounting plate with integrated mounting hardware
- Material: 6063-T5 Aluminum alloy base plate
- Surface Treatment: Hard anodized (25-30μm thickness)
- Mounting Hole Pattern: ISO 15552 standard (32mm bore cylinder compatible)
- Bolt Specifications: M6×20mm (Class 8.8 hex socket screws included)
- Thread Engagement Depth: 12mm minimum
- Mounting Surface Flatness: ≤0.05mm
- Operating Temperature: -20°C to 80°C
- Surface Hardness: HV 400-450
- Weight: 480g ±2%
- Dimensions: 72mm(L) × 42mm(W) × 14mm(H)
- Center Bore Diameter: Ø32.2mm (+0.1/-0 mm)
- Mounting Hole Spacing: 60mm × 30mm (Longitudinal × Transverse)
- Corrosion Resistance: 96hrs salt spray test passed
Precision-machined mounting solution for ISO 15552 series pneumatic cylinders, featuring anti-vibration design with diamond-knurled contact surfaces. Includes stainless steel shim washers (0.5mm thickness) for alignment compensation. Compatible with both NFPA and ISO mounting standards through adaptive hole patterns.
Application Scenarios:
- Robotic arm joint articulation systems
- High-cycle packaging machinery linear actuators
- CNC machine tool clamping mechanisms
- Automated assembly line positioning units
- Food processing equipment with washdown requirements
Installation Protocol:
Apply 25-35N·m torque during mounting. Use included anti-seize compound
on threads for stainless-steel interfaces. Validate perpendicularity
with 0.02mm/m precision level before final tightening sequence.
Note: Requires pairing with AirTAC SI series cylinder
rod-end accessories (F-SI-* models). Not compatible with compact cylinder
variants below 25mm bore size. For vertical mounting, use supplementary
support bracket AD-FM32V.
