Airtac F-SI-FA Front Flange Mounting Plate Assembly F-SI50FA
$10.66
Regular price
$18.16
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SI50FA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Description:
**Category:** Pneumatic Cylinder Mounting Kits
**Brand:** AirTAC
**Series:** F-SI-FA
A precision-engineered front flange mounting solution designed for seamless integration with ISO-standard pneumatic cylinders. This complete assembly features a robust anodized aluminum alloy construction with CNC-machined mounting surfaces, ensuring dimensional accuracy and vibration resistance. The pre-assembled design simplifies cylinder installation while maintaining strict axial alignment tolerances. Includes grade 12.9 high-tensile steel fasteners and anti-loosening measures for secure mounting in high-cycle industrial applications. Compatible with ISO 6431/15552 cylinder profiles.
**Key Applications:**
• Linear actuator stabilization in automation systems
• Modular pneumatic circuit assembly
• Precision positioning setups requiring minimal deflection
**Technical Highlights:**
- Corrosion-resistant surface treatment (MIL-A-8625 compliant)
- Integrated load-bearing reinforcement ribs
- ±0.05mm bore concentricity tolerance
- Operating temperature range: -20°C to +80°C
Installation protocol:
Apply medium-strength thread locker (Loctite 243 recommended) to mounting bolts.
Tighten in cross pattern sequence at 50%→80%→100% torque stages.
Verify perpendicularity with 0.02mm precision level within 30 minutes of installation.
AirTAC F-SI-FA Front Flange Mounting Kit (F-SI50FA) Specifications
- Model: F-SI50FA
- Type: Pre-assembled front flange mounting plate kit
- Material: Aluminum alloy (AL6063-T5)
- Surface treatment: Black anodized
- Mounting hole pattern: Compatible with SDA/SDB/SUD series 50mm bore cylinders
- Bolt specifications: M6×20 (Class 8.8 hex socket head cap screws included)
- Thread engagement depth: 15mm ±0.5mm
- Mounting torque: 6.4-7.2 N·m (using M6 bolts)
- Temperature range: -20℃ to 80℃
- Dynamic load capacity: 300N (axial direction)
- Static load capacity: 800N (radial direction)
- Weight: 0.85kg ±3%
- Dimensions: 200mm(L) × 50mm(W) × 20mm(H)
- Flatness tolerance: ≤0.05mm/m
- Parallelism: ≤0.1mm across mounting surface
Precision-machined flange kit designed for rigid cylinder mounting in high-cycle applications. Features vibration-resistant design with 4-point bolt fixation and hardened steel bushings. Includes pre-installed alignment pins (Ø8h7) for rapid installation. Compatible with ISO 15552 standard profiles.
Typical Applications:
- Industrial robotic arm joint articulation
- Packaging machine vertical lift mechanisms
- Automated welding fixture positioning
- CNC tool changer cylinder mounting
- Plastic injection molding ejector systems
Installation protocol:
Apply medium-strength thread locker (Loctite 243 recommended) to mounting bolts.
Tighten in cross pattern sequence at 50%→80%→100% torque stages.
Verify perpendicularity with 0.02mm precision level within 30 minutes of installation.
Note: Requires mating with ISO 21287 flange-bearing cylinders.
Not suitable for applications exceeding 15Hz vibration frequency or
continuous side moment loads above 50N·m.
