Airtac F-SI-TC Middle Trunnion Bracket Assembly Kit F-SI63TC
AirTAC F-SI-TC Series Center Pivot Bracket Kit F-SI63TC Technical Details
- Model: F-SI63TC (Complete Kit)
- Series: F-SI-TC Intermediate Trunnion Bracket
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (Black/Silver optional)
- Mounting hole spacing: 30±0.2mm (Horizontal) × 25±0.2mm (Vertical)
- Thread specifications: M8×1.25 mounting threads (4 places)
- Load capacity: 300kg static / 150kg dynamic
- Operating temperature: -20℃ to +80℃
- Weight: 0.25kg ±5%
- Dimensions: 80mm(L) × 40mm(W) × 25mm(H)
- Included components: Bracket body, M8×20 hex socket screws (4pcs), anti-vibration washers (4pcs), installation guide
- Corrosion resistance: 96hr salt spray test passed
Precision-machined pivot bracket designed for precise actuator alignment in pneumatic systems. Features CNC-milled mounting surfaces with ±0.05mm parallelism tolerance, ensuring vibration damping and load distribution. The hardened steel threaded inserts provide 50% greater pull-out resistance compared to standard aluminum threads.
- Rod-style cylinder mounting in pick-and-place robots
- Pneumatic actuator support in conveyor sorting systems
- Linear guide reinforcement for CNC tool changers
- Shock absorption in stamping machine linkages
- Multi-axis alignment in semiconductor handling equipment
Installation protocol:
Apply 2.5-3.0N·m torque using calibrated torque wrench during assembly.
Lubricate contact surfaces with molybdenum disulfide grease (ISO-L-XBCHB 2)
before high-cycle installations. Periodic re-torque recommended after
first 500 operating hours.
Optimized for ISO 8573-1:2010 Class 3 air quality environments. Avoid direct exposure to alkaline solutions (pH >9) which may degrade anodized layer.
| Property | Property Value |
|---|---|
| sku | F-SI63TC |
