Airtac F-SI-TCM Trunnion Mount Complete Assembly Kit F-SI160TCM2
AirTAC F-SI-TCM Trunnion Bracket Kit F-SI160TCM2 Technical Details
- Model: F-SI160TCM2
- Type: Precision-engineered trunnion mount assembly
- Material: Aluminum alloy (AL6061-T6)
- Load capacity: 1,800N dynamic / 3,600N static
- Mounting type: Dual-axis adjustable trunnion
- Dimensions: 160mm(L) × 120mm(W) × 75mm(H)
- Weight: 2.8kg ±3%
- Surface treatment: Hard anodized (25-30μm thickness)
- Operating temperature: -40℃ to 150℃
- Mounting holes: 4× M10 threaded (8.8 grade bolts included)
- Alignment tolerance: ±0.15mm concentricity
- Vibration resistance: 5-2000Hz, 10G max
- Corrosion resistance: 500hrs salt spray test compliant
- Included components: Bracket body, alignment shims (0.1/0.2/0.5mm), mounting hardware kit, anti-vibration pads
- Compliance: ISO 9001, RoHS
Heavy-duty trunnion mounting solution designed for precision alignment of pneumatic actuators and linear guides. Features military-grade anodization and dual-axis micro-adjustment (±3° vertical/horizontal) for critical positioning applications. Includes vibration-damping inserts for high-cycle industrial environments.
- Robotic arm pivot mounting in automotive assembly
- High-speed packaging machine guide rail support
- CNC tool changer actuator stabilization
- Semiconductor handling robot base frame
- Material testing machine load cell mounting
Installation protocol:
Use torque-controlled wrench (14-16N·m for M10 bolts) with sequential tightening pattern.
Apply MOBILITH SHC 100 grease on adjustment surfaces pre-assembly.
Perform laser alignment check after 50 operating hours.
