Airtac F-TCM Repair Kit P-TCM10-R1
$3.48
Regular price
$10.98
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
P-TCM10-R1
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Pneumatic Cylinder Seal Kits
Brand: AirTAC
Series: F-TCM The AirTAC F-TCM Repair Kit is a professional-grade sealing solution pack specifically engineered for pneumatic cylinder maintenance. Containing genuine OEM components, this kit features precision-molded seals and wear rings compliant with ISO 6431/15552 standards. Designed for F-TCM series cylinders, it ensures optimal compression resistance (up to 1MPa) and temperature stability (-20°C to +80°C). Includes critical wear components: piston seals, rod seals, guide rings, and O-rings manufactured from NBR/PU compounds. The comprehensive kit facilitates efficient cylinder overhaul while maintaining original equipment performance parameters. Recommended for preventive maintenance cycles in automation systems requiring IP65-rated sealing integrity.
Maintenance protocol:
Always perform barrel honing inspection before installation.
Use torque-controlled tools (0.8-1.2Nm) for screw reassembly.
Pressure test at 1.5× operating pressure for 10 minutes post-repair.
Brand: AirTAC
Series: F-TCM The AirTAC F-TCM Repair Kit is a professional-grade sealing solution pack specifically engineered for pneumatic cylinder maintenance. Containing genuine OEM components, this kit features precision-molded seals and wear rings compliant with ISO 6431/15552 standards. Designed for F-TCM series cylinders, it ensures optimal compression resistance (up to 1MPa) and temperature stability (-20°C to +80°C). Includes critical wear components: piston seals, rod seals, guide rings, and O-rings manufactured from NBR/PU compounds. The comprehensive kit facilitates efficient cylinder overhaul while maintaining original equipment performance parameters. Recommended for preventive maintenance cycles in automation systems requiring IP65-rated sealing integrity.
AirTAC F-TCM Repair Kit P-TCM10-R1 Technical Details
- Model: P-TCM10-R1 (F-TCM Series Repair Kit)
- Compatible Cylinder Series: SC/SU/SD 32-100mm bore sizes
- Seal Types Included: Quad-ring (X-ring), O-ring, Dust Seal
- Material Composition: HNBR (Hydrogenated Nitrile) rubber seals
- Temperature Tolerance: -30℃ to 120℃
- Pressure Range: 0.05–1.2 MPa
- Weight: 320g ±5g (including packaging)
- Package Dimensions: 180mm(L) × 95mm(W) × 25mm(H)
- Component Count: 18 precision parts
- Lubrication: Pre-coated with PTFE-based grease
- Storage Life: 5 years in original sealed packaging
Comprehensive maintenance solution for F-TCM series compact cylinders, containing wear-resistant seals and critical components for full pneumatic circuit overhaul. Features anti-extrusion design for high pulse resistance, optimized for high-cycle applications.
Implementation Guidelines:
- Mandatory replacement cycle: Every 500,000 cycles or 2 years (whichever comes first)
- Requires ISO 8573-1 Class 3 compressed air
- Compatible with ISO VG32 hydraulic oil for lubrication
- Max lateral load capacity after repair: 50N
Industrial Applications:
- Automated semiconductor handling robots
- High-speed packaging machine clamp mechanisms
- CNC machine tool chip conveyors
- Pharmaceutical blister packaging units
Maintenance protocol:
Always perform barrel honing inspection before installation.
Use torque-controlled tools (0.8-1.2Nm) for screw reassembly.
Pressure test at 1.5× operating pressure for 10 minutes post-repair.
| Property | Property Value |
|---|---|
| sku | P-TCM10-R1 |
