Airtac F-TCM Repair Kit P-TCM16-R2
Brand: AirTAC
Series: F-TCM The AirTAC F-TCM Repair Kit is a professional-grade sealing solution pack specifically engineered for pneumatic cylinder maintenance. Containing genuine OEM components, this kit features precision-molded seals and wear rings compliant with ISO 6431/15552 standards. Designed for F-TCM series cylinders, it ensures optimal compression resistance (up to 1MPa) and temperature stability (-20°C to +80°C). Includes critical wear components: piston seals, rod seals, guide rings, and O-rings manufactured from NBR/PU compounds. The comprehensive kit facilitates efficient cylinder overhaul while maintaining original equipment performance parameters. Recommended for preventive maintenance cycles in automation systems requiring IP65-rated sealing integrity.
AirTAC F-TCM Repair Kit P-TCM16-R2 Technical Details
- Kit Part Number: P-TCM16-R2
- Compatible Models: TCM16-F/AC/AD/AE series directional control valves
- Included Components: Spool seals, O-rings (NBR/FKM), spring set, backup rings, guide sleeves
- Seal Material Options: Standard NBR (-20℃ to 80℃) / Optional FKM (-10℃ to 150℃)
- Pressure Range: 0.1-0.8 MPa
- Chemical Resistance: Compatible with phosphate ester oil, water glycol, and most industrial fluids
- Weight: 85g ±2g (complete kit with packaging)
- Dimensions: 120mm(L) × 85mm(W) × 25mm(H) (flat-packed blister package)
- Shelf Life: 5 years in original sealed packaging
- Replaces Components: Original part numbers TCM16-005/008/012 series wear parts
Comprehensive maintenance kit for TCM16 series compact pneumatic valves, containing all critical wear components for full valve overhaul. Features precision-molded seals with controlled compression ratios (20-30% for static seals, 15-20% for dynamic seals) to maintain original valve performance characteristics.
- Preventive maintenance cycles (recommended every 5 million cycles)
- Emergency repair of leaking valves in automated assembly lines
- Valve refurbishment for food/pharma applications requiring material upgrades
- Field service operations requiring compact repair solution
- Depressurize system and disassemble valve body
- Clean components with isopropyl alcohol (do not use mineral spirits)
- Replace all seals using provided installation tool (included)
- Apply silicone-free grease (viscosity 100-150 mm²/s at 40℃)
- Reassemble with 0.5-0.6 N·m torque on fasteners
Maintenance tip:
Always replace complete seal set - partial replacement may cause uneven wear.
Test repaired valves at 0.6 MPa for 3 cycles before returning to service.
| Property | Property Value |
|---|---|
| sku | P-TCM16-R2 |
