Airtac F-TCM Repair Kit P-TCM25-R2
Brand: AirTAC
Series: F-TCM The AirTAC F-TCM Repair Kit is a professional-grade sealing solution pack specifically engineered for pneumatic cylinder maintenance. Containing genuine OEM components, this kit features precision-molded seals and wear rings compliant with ISO 6431/15552 standards. Designed for F-TCM series cylinders, it ensures optimal compression resistance (up to 1MPa) and temperature stability (-20°C to +80°C). Includes critical wear components: piston seals, rod seals, guide rings, and O-rings manufactured from NBR/PU compounds. The comprehensive kit facilitates efficient cylinder overhaul while maintaining original equipment performance parameters. Recommended for preventive maintenance cycles in automation systems requiring IP65-rated sealing integrity.
AirTAC F-TCM Repair Kit P-TCM25-R2 Technical Details
- Model: P-TCM25-R2
- Compatible Series: F-TCM20/25/32 cylinders
- Package Contents: Piston seals, rod seals, wear rings, O-rings, backup rings
- Seal Material: NBR (Nitrile) & PU (Polyurethane) compounds
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Pressure Rating: 0.05-1.0 MPa
- Weight: 220g ±5% (including packaging)
- Dimensions: 150mm(L) × 80mm(W) × 25mm(H)
- Storage Humidity: ≤85% RH (non-condensing)
- Certification: RoHS compliant
- Shelf Life: 5 years in original sealed packaging
Complete overhaul kit for F-TCM series compact cylinders, containing precision-molded replacement components engineered to restore original equipment performance. Features oil/fuel-resistant seals and anti-extrusion rings designed for high-cycle applications. Includes wear-resistant guide elements to prevent metal-to-metal contact.
- Preventive maintenance of automated assembly line actuators
- Overhauling contaminated cylinders in food processing machinery
- Replacement of worn seals in high-speed packaging equipment
- Restoring pneumatic grippers in robotic systems
- Field service repairs for material handling systems
Maintenance protocol:
Always clean cylinder bore with alcohol-based solvent before installation.
Apply AirTAC PNEUMATIC Grease No.2 (PG-02) to seals. Replace entire seal set
simultaneously - partial replacement may cause uneven wear.
| Property | Property Value |
|---|---|
| sku | P-TCM25-R2 |
