Airtac F-TCM Repair Kit P-TCM63-R1
Brand: AirTAC
Series: F-TCM The AirTAC F-TCM Repair Kit is a professional-grade sealing solution pack specifically engineered for pneumatic cylinder maintenance. Containing genuine OEM components, this kit features precision-molded seals and wear rings compliant with ISO 6431/15552 standards. Designed for F-TCM series cylinders, it ensures optimal compression resistance (up to 1MPa) and temperature stability (-20°C to +80°C). Includes critical wear components: piston seals, rod seals, guide rings, and O-rings manufactured from NBR/PU compounds. The comprehensive kit facilitates efficient cylinder overhaul while maintaining original equipment performance parameters. Recommended for preventive maintenance cycles in automation systems requiring IP65-rated sealing integrity.
AirTAC F-TCM Repair Kit P-TCM63-R1 Technical Details
- Repair Kit Code: P-TCM63-R1
- Compatible Series: F-TCM63 series compact tandem cylinders
- Seal Types Included: 4x U-cup seals (PU material), 2x rod seals (NBR), 3x wear rings (PTFE composite)
- Gasket Specifications: 0.5mm thick EPDM cushion plates (set of 6)
- Spring Components: Chrome silicon return springs (2pc, Ø3.2×28mm)
- Lubrication: Pre-coated with silicone-free grease (Molykote EM-50L equivalent)
- Temperature Tolerance: -30℃ to 100℃ (seal operational range)
- Pressure Rating: Compatible with 0.05-1.0 MPa systems
- Weight: 320g ±5% (including all components and packaging)
- Package Dimensions: 180mm(L) × 95mm(W) × 25mm(H) (flat blister pack)
- Storage Life: 5 years in original sealed packaging
Complete maintenance solution for F-TCM63 compact cylinders, containing wear-resistant seals and precision components designed for 500,000+ cycle durability. Features low-friction materials optimized for high-speed automation applications (0.5-1.5 m/s piston speeds). Includes anti-extrusion rings for side load protection.
- Preventive maintenance in SMT equipment pick-and-place units
- Overhaul of pharmaceutical blister packaging machine actuators
- Field repair of automated warehouse vertical lift mechanisms
- Restoration of semiconductor wafer handling robots
Installation protocol:
Requires ISO 8573-1 Class 3 air quality. Use torque-controlled assembly (3-5Nm for end caps).
Perform 50-100 test cycles before returning to service. Replace entire seal set simultaneously.
• Matches original part numbers: TCM63-U1 (rod seals), TCM63-P2 (piston seals)
• Alternative to SMC CQ2 series repair kits when using adapter shims
| Property | Property Value |
|---|---|
| sku | P-TCM63-R1 |
