Airtac P-4M Adapter Plate P-4M300-R1
AirTAC P-4M Transition Plate P-4M300-R1 Technical Specifications
- Model: P-4M300-R1
- Type: Universal transition/adapter plate
- Material: Aluminum alloy 6063-T5
- Surface treatment: Anodized (black)
- Mounting pattern: ISO 21287 standard compliant
- Bore spacing: 300mm center-to-center
- Thickness: 20mm ±0.1mm
- Mounting hole size: M6 threaded (8 holes)
- Operating pressure: ≤1.0 MPa
- Temperature range: -20℃ to 150℃
- Weight: 1.85 kg ±3%
- Dimensions: 320mm(L) × 40mm(W) × 20mm(H)
- Flatness tolerance: ≤0.05mm/m
- Surface roughness: Ra 1.6μm
High-precision mounting interface plate designed for modular pneumatic system integration. Features stress-relieved construction with CNC-machined datum surfaces for accurate alignment between actuators and peripheral components. Includes integrated O-ring grooves for optional sealing applications.
- Multi-axis actuator array synchronization
- Robotic end-effector mounting platforms
- Modular assembly line fixture transitions
- Precision grinding machine tool adaptations
- Semiconductor handling equipment interfaces
Installation protocol:
Clean mounting surfaces with IPA before assembly. Use torque-limiting wrench
(recommended 5.5-6.0 N·m for M6 screws) and alternate tightening sequence
to prevent warping. Apply anti-seize compound on threads for maintenance access.
| Property | Property Value |
|---|---|
| sku | P-4M300-R1 |
