Airtac P-MAL Repair Kit P-MAL20-R1
Brand: AIRTAC
Series: P-MAL Repair Kit
The AIRTAC P-MAL Cylinder Seal Repair Kit is a precision-engineered maintenance solution specifically designed for pneumatic cylinder overhaul. This OEM-grade kit contains complete sealing components including:
- Nitrile rubber O-rings
- Polyurethane piston seals
- Rod seals and wipers
- Specialized guide rings
Fully compliant with ISO 6431/6432 standards, the kit ensures optimal dimensional accuracy and material compatibility with original P-MAL series cylinders. Featuring enhanced wear resistance and low-friction characteristics, these seals maintain cylinder efficiency while preventing air leakage and pressure drop. Essential for preventive maintenance and cylinder rehabilitation in industrial automation systems.
AirTAC P-MAL20-R1 Repair Kit Technical Details
- Model: P-MAL20-R1
- Compatible Valve Series: MAL20 5-port directional valves
- Seal Material: NBR (Nitrile) & FKM (Fluorocarbon) compound
- Components Included:
- 4x Spool shaft seals (Φ5mm)
- 2x Piston O-rings (Φ18mm)
- 1x Spring set (stainless steel)
- 6x Port seat gaskets
- 1x Manual override repair sleeve
- Temperature Range: -20°C to 120°C (continuous use)
- Pressure Rating: 0.05-1.0 MPa (matches MAL20 valve specs)
- Chemical Resistance: Resists hydraulic oils, weak acids, and alkalis
- Weight: 185g ±5g (including anti-static packaging)
- Dimensions: 120mm(L) × 95mm(W) × 35mm(H)
- Shelf Life: 8 years in original sealed packaging
- Certification: RoHS compliant
Complete overhaul kit for restoring MAL20 series valve performance, containing wear-resistant seals and critical replacement parts. Features dual-material seals that balance elasticity and high-temperature stability. Kit components are vacuum-sealed in numbered compartments for sequential assembly.
- Preventive maintenance of pneumatic assembly line systems
- Repairing air leakage in automated packaging machinery
- Valve refurbishment for semiconductor manufacturing tools
- Field service repairs on robotic material handlers
Maintenance protocol:
Replace all seals simultaneously using included alignment jig.
Apply silicone grease (ISO VG 10-20) before installation.
Torque housing screws to 0.8-1.2 N·m in cross pattern sequence.
