Airtac P-SCT Repair Kit P-SCT50N-R1
AirTAC P-SCT50N-R1 Cylinder Repair Kit Technical Details
- Model: P-SCT50N-R1
- Compatible Series: SCT50N standard cylinder series
- Components Included: Piston seals, rod seals, O-rings, wiper seals, cushion rings, retaining rings
- Material Composition: NBR (Nitrile) + PU (Polyurethane) hybrid seals
- Temperature Tolerance: -20°C to +80°C (continuous operation)
- Pressure Rating: Matches SCT50N cylinder specs (0.05-1.0 MPa)
- Weight: 0.15 kg ±5% (complete kit)
- Dimensions: 120mm(L) × 80mm(W) × 25mm(H) (vacuum-sealed package)
- Storage Humidity: ≤75% RH (original packaging)
- Shelf Life: 3 years from manufacture date (unopened)
- Compliance: ISO 6431, JIS B8377 standards
Professional maintenance solution for SCT series compact cylinders, containing 12 precision-matched components to restore factory-grade sealing performance. Features wear-compensated seal designs and anti-extrusion rings for high-cycle applications. Includes specially formulated silicone-free lubricant compatible with ISO VG32 hydraulic fluids.
- Overhaul cycles: Recommended every 500,000 cycles or 12 months (whichever comes first)
- Ideal for: Food processing machinery requiring NSF H1 grease compatibility
- Critical replacement indicators: Air leakage >15% of rated flow, visible rod scoring
- Post-repair testing: Requires 3x full-stroke actuation at 0.5 MPa before system reintegration
Maintenance protocol:
Always replace entire seal set (partial replacement voids warranty).
Clean cylinder bore with alcohol-free solvent and inspect for
concentricity (max 0.02mm deviation) before assembly.
| Property | Property Value |
|---|---|
| sku | P-SCT50N-R1 |
