Airtac P-TR Repair Kit P-TR10-R1
AirTAC P-TR10-R1 Repair Kit Technical Details
- Kit code: P-TR10-R1
- Compatible series: PTR10 pneumatic regulators
- Components included: Diaphragm seals, O-rings (NBR), spring set, valve poppet, dust seal
- Material specifications:
- Elastomers: Oil-resistant NBR (70±5 Shore A)
- Spring: SUS304 stainless steel
- Metal parts: Anodized aluminum alloy
- Operating temperature: -20℃ to 80℃ (continuous use)
- Pressure range: 0.05-0.95 MPa
- Weight: 85g ±3g (entire kit)
- Package dimensions: 120mm(L) × 75mm(W) × 25mm(H)
- Storage conditions: Dry environment below 40℃/70% RH
- Compliance: RoHS 2011/65/EU compliant
Complete maintenance solution for PTR series pressure regulators, containing all wear-prone components for full pneumatic circuit rehabilitation. Features color-coded seals and anti-corrosion treated parts for extended service life. Kit components are pre-lubricated with silicone-free grease for immediate installation.
- Industrial pneumatic system overhauls
- Preventive maintenance cycles (recommended every 5000h)
- Emergency repair of pressure fluctuation issues
- Retrofitting older regulators to current specifications
Maintenance protocol:
Replace entire seal set during overhaul. Clean metal surfaces with non-petroleum solvent before assembly.
Torque housing screws to 0.8-1.2 N·m using crisscross pattern.
