Airtac P-TR Repair Kit P-TR32-R1
AirTAC P-TR32-R1 Repair Kit Technical Details
- Repair Kit Code: P-TR32-R1
- Compatible Series: TR32 cylinder models (TR32x50~TR32x500)
- Seal Material: Polyurethane (PU) & Nitrile Rubber (NBR)
- Included Components:
- Piston seals (2 pcs)
- Rod seals (2 pcs)
- Wiper seals (2 pcs)
- O-rings (4 pcs - sizes 18x2.4mm, 22x2.4mm)
- Backup rings (2 pcs PTFE)
- Cushion seals (optional per cylinder configuration)
- Pressure Range: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Weight: 220g ±5g
- Package Dimensions: 150mm(L) × 95mm(W) × 25mm(H)
- Storage Life: 5 years in original packaging
- Compliance: RoHS 2.0 compliant
Complete overhaul kit for TR32 series cylinders, containing wear-resistant seals specifically engineered for high-cycle applications. Features anti-extrusion designs with integrated backup rings for improved pressure resistance. Kit components are vacuum-sealed in partitioned trays to prevent deformation during storage.
- Cylinder leakage repair in automated assembly lines
- Preventive maintenance for food packaging machinery
- Overhaul of pneumatic actuators in automotive welding systems
- Restoration of medical equipment actuators requiring FDA-compliant seals
- Disassemble cylinder using TR-series specific wrench set
- Clean all metal components with non-petroleum solvent
- Lubricate new seals with silicone grease (ISO VG 10-15)
- Install seals with marked orientation facing pressure side
- Perform 5-10 test strokes before returning to service
Critical Note:
Always replace complete seal set to maintain pressure balance.
Never mix old/new seals or different material types.
Torque end bolts to 12-15N·m during reassembly.
