Airtac F-ACA-LM Positioning Stop Nut Assembly Kit F-ACA10LM
$3.48
Regular price
$10.98
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-ACA10LM
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Hydraulic Shock Absorber
Brand: AirTAC
Series: F-ACA-LM Positioning Stop Nut Kit
Technical Description:
The F-ACA-LM Positioning Stop Nut Kit is an engineered accessory package designed for precision alignment and axial positioning in hydraulic damping systems. Featuring ISO-standard metric threads and hardened surface treatment, this kit ensures secure locking functionality while maintaining vibration resistance in high-cycle industrial applications.
Key Specifications:
• Material: Chromium-molybdenum alloy steel (SCM435 equivalent)
• Surface Hardness: HRC 35-40
• Thread Tolerance: 6g per ISO 965-1
• Anti-loosening Design: Deformation-prevention groove configuration
Application Compatibility:
Specifically optimized for F-ACA-LM series hydraulic shock absorbers, this kit provides micron-level positioning accuracy for automated equipment requiring repeatable stroke termination. Includes installation-ready components with pre-lubricated interfaces for immediate OEM integration.
Installation protocol:
Use 17mm hex key for 1/4 turn past hand-tight position. Apply thread locker (LOCTITE 243 recommended)
for high-vibration environments. Re-torque after 24hrs of initial operation.
AirTAC F-ACA-LM Positioning Stop Nut Kit F-ACA10LM Technical Details
- Full model: F-ACA10LM (Complete Kit)
- Thread specification: M10×1.5 (Metric fine thread)
- Material: Case-hardened carbon steel SCr420
- Surface treatment: Black oxide coating (8-12μm)
- Locking torque range: 5-15 N·m
- Operating temperature: -30℃ to 120℃
- Vibration resistance: ≤15 m/s² (ISO 10816-3)
- Repeat positioning accuracy: ±0.02 mm
- Package contents: 1 nut + 2 lock washers + installation tool
- Weight: 48g ±2g (per complete set)
- Dimensions: 22mm(Ø) × 18mm(H) (Hex size 17mm)
- Compatible rods: Φ10mm linear shafts (h6 tolerance)
- Lubrication: Pre-applied Molykote PG-65 grease
Precision-engineered mechanical stop solution with integrated anti-loosening design. Features dual-stage locking through deformed thread geometry and spring washer redundancy. The hardened construction withstands over 50,000 impact cycles at rated load.
Industrial Applications:
- Linear actuator end-position calibration
- CNC machine tool limit adjustment
- Robotic arm repeat position locking
- Packaging equipment stroke control
- Semiconductor wafer stage mechanical stops
Installation protocol:
Use 17mm hex key for 1/4 turn past hand-tight position. Apply thread locker (LOCTITE 243 recommended)
for high-vibration environments. Re-torque after 24hrs of initial operation.
Warning: Not compatible with stainless steel rods due to galling risk.
For aluminum alloys, use maximum 7 N·m torque with PTFE-based lubricant.
| Property | Property Value |
|---|---|
| sku | F-ACA10LM |
| Internal Thread Specification | M10 |
