Airtac F-ACA-LM Positioning Stop Nut Assembly Kit F-ACA33LM
$10.20
Regular price
$17.70
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-ACA33LM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Hydraulic Shock Absorber
Brand: AirTAC
Series: F-ACA-LM Positioning Stop Nut Kit
Technical Description:
The F-ACA-LM Positioning Stop Nut Kit is an engineered accessory package designed for precision alignment and axial positioning in hydraulic damping systems. Featuring ISO-standard metric threads and hardened surface treatment, this kit ensures secure locking functionality while maintaining vibration resistance in high-cycle industrial applications.
Key Specifications:
• Material: Chromium-molybdenum alloy steel (SCM435 equivalent)
• Surface Hardness: HRC 35-40
• Thread Tolerance: 6g per ISO 965-1
• Anti-loosening Design: Deformation-prevention groove configuration
Application Compatibility:
Specifically optimized for F-ACA-LM series hydraulic shock absorbers, this kit provides micron-level positioning accuracy for automated equipment requiring repeatable stroke termination. Includes installation-ready components with pre-lubricated interfaces for immediate OEM integration.
Installation protocol:
Apply included lubricant to male threads before assembly. Use crisscross tightening pattern and verify final position with dial indicator. Re-torque after 50 operating cycles.
Critical note:
Not compatible with aluminum alloy cylinders. Maximum 3 reuses recommended due to spring tension degradation. Replace immediately if radial play exceeds 0.05mm.
AirTAC F-ACA-LM Positioning Stop Nut Kit F-ACA33LM Technical Details
- Full model designation: F-ACA33LM (Complete kit with pre-assembled components)
- Thread specification: M33×1.5 metric fine thread
- Compatible cylinder series: AC(A)Q series standard cylinders
- Material composition:
- Nut body: Carbon steel S45C
- Locking element: Spring steel with zinc-nickel plating
- Sealing washer: Special nylon polymer
- Surface treatment: Black oxide coating (Fe/Of) for corrosion resistance
- Installation torque: 50-60 N·m (requires calibrated torque wrench)
- Axial load capacity: 1,200 kg (static)/800 kg (dynamic)
- Operating temperature: -30℃ to 120℃
- Vibration resistance: 5-2000 Hz, 3G acceleration
- Weight: 184g ±2% (per complete nut assembly)
- Dimensions: 42mm(OD) × 19.5mm(Height) × 8mm(Washer thickness)
- Package contents:
- 1× Position lock nut
- 2× Anti-rotation tab washers
- 1× Thread lubricant packet (Molykote 111)
Precision-engineered mechanical locking solution for cylinder stroke adjustment, featuring triple-stage thread engagement and wear-compensation design. The zinc-nickel plated spring collar provides 360° positive locking without thread deformation. Includes pre-lubricated threads to prevent galling during installation.
Implementation Scenarios:
- Multi-position programmable logic controller (PLC) automation lines
- Die-casting machine cylinder end position fixation
- Robotic arm repeat positioning systems (RPS)
- High-cycle packaging equipment with shock loads
- Rail-guided transfer systems requiring micron-level positioning
Installation protocol:
Apply included lubricant to male threads before assembly. Use crisscross tightening pattern and verify final position with dial indicator. Re-torque after 50 operating cycles.
Critical note:
Not compatible with aluminum alloy cylinders. Maximum 3 reuses recommended due to spring tension degradation. Replace immediately if radial play exceeds 0.05mm.
