Airtac F-ACA-LM Positioning Stop Nut Assembly Kit F-ACA36LM
AirTAC F-ACA-LM Positioning Stop Nut Kit F-ACA36LM Technical Details
- Full model designation: F-ACA36LM (Complete Kit)
- Thread specification: M36×1.5 precision ground
- Material composition:
- Nut body: SCr420 alloy steel
- Locking mechanism: SUS304 stainless steel inserts
- Surface treatment: Black oxide coating + anti-rust oil
- Static load capacity: 12,500 N (axial)
- Dynamic load rating: 8,200 N @ 1Hz cyclic loading
- Torque specifications:
- Installation torque: 180-220 N·m
- Locking collar torque: 25-30 N·m
- Weight: 487g ±5g (complete assembly)
- Dimensions:
- Outer diameter: 62mm
- Height: 38mm (including locking collar)
- Flange thickness: 12mm
- Temperature tolerance: -30℃ to 120℃ (continuous operation)
- Vibration resistance: 5-2000Hz, 15G peak
- Compatibility: Matches AG/SC standard guide rod profiles
High-precision mechanical locking solution designed for industrial linear motion systems. Features dual-stage security with primary thread engagement and secondary collar locking. The phosphated surface treatment provides corrosion resistance in humid environments while maintaining precise dimensional stability (±0.01mm tolerance). Includes pre-lubricated threads with molybdenum disulfide coating for smooth adjustment.
- CNC machine tool Z-axis positioning locks
- Automated warehouse vertical lift braking systems
- Robotic arm repeat position calibration fixtures
- Precision optical stage mechanical stops
- Die casting machine platen height stabilization
Installation protocol:
Apply initial preload torque in 3 progressive stages (50%, 75%, 100% of spec).
Use thread locker compound only on collar threads, never on main engagement surfaces.
Re-torque after first 50 operational cycles.
| Property | Property Value |
|---|---|
| sku | F-ACA36LM |
| Internal Thread Specification | M36x1.5 |
