Airtac F-HGS-J Stroke Adjustment Screw F-HGS10X10J
$32.53
Regular price
$40.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-HGS10X10J
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
F-HGS-J Stroke Adjustment Screw Set
Category: Magnetic Sensors | Brand: AirTAC | Series: F-HGS-J [Professional Note: This finished screw set is designed for precise stroke calibration in pneumatic systems, compatible with F-HGS-J series magnetic switches. Features hardened steel construction with anti-corrosion treatment, ensuring durability and repeatable adjustment accuracy in industrial automation applications.]
Installation protocol:
Apply MOBILUX EP2 grease to threads before initial use.
Tighten locknut to 12-15N·m torque after adjustment.
Maximum recommended cycling speed: 120 adjustments/minute.
Category: Magnetic Sensors | Brand: AirTAC | Series: F-HGS-J [Professional Note: This finished screw set is designed for precise stroke calibration in pneumatic systems, compatible with F-HGS-J series magnetic switches. Features hardened steel construction with anti-corrosion treatment, ensuring durability and repeatable adjustment accuracy in industrial automation applications.]
AirTAC F-HGS-J Series Stroke Adjustment Screw F-HGS10X10J Technical Details
- Full Model: F-HGS10X10J
- Type: Precision stroke adjustment screw with locking nut
- Material: Carbon steel (SCM435 equivalent)
- Surface treatment: Nickel plating (5-8μm thickness)
- Thread specification: M10×1.5 (coarse pitch metric thread)
- Effective stroke: 10mm (±0.5mm adjustment range)
- Total length: 50mm
- Shaft diameter: 8mm
- Hexagon size: 10mm AF
- Locknut dimensions: 15mm OD × 6mm thickness
- Weight: 35g ±2g
- Operating temperature: -20℃ to 120℃
- Maximum load capacity: 500N axial force
- Surface hardness: HV450-550
- Corrosion resistance: 96hrs neutral salt spray test passed
Precision-engineered mechanical stop component with dual-stage locking mechanism (spring washer + hex nut). Features anti-backlash design with PTFE-impregnated threads for smooth micro-adjustments. Compatible with ISO 4026/4029 standard mounting configurations.
Implementation Scenarios:
- Pneumatic cylinder end position fine-tuning in SMT assembly lines
- Mechanical press stroke calibration systems
- Robotic arm joint movement limitation adjustment
- Packaging machine product thickness compensation
- CNC tool changer position verification
Installation protocol:
Apply MOBILUX EP2 grease to threads before initial use.
Tighten locknut to 12-15N·m torque after adjustment.
Maximum recommended cycling speed: 120 adjustments/minute.
Preventive measures:
Perform thread debris cleaning every 50,000 cycles.
Replace if axial play exceeds 0.2mm.
Avoid chemical contact with pH <4 or >11 solutions.
| Property | Property Value |
|---|---|
| sku | F-HGS10X10J |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
