Airtac F-HLS-A Front and Rear End with Stroke Adjustment Screws Kit F-HLS12A
$27.88
Regular price
$35.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-HLS12A
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Cylinder Accessories
Brand: AirTAC
Series: F-HLS-A Front/Rear Mounted Stroke Adjustment Screw Kit
Professional-grade pneumatic cylinder accessory designed for precise stroke adjustment in automation systems. Features dual-end screw mechanisms (front/rear) with fine-threaded adjustment for optimized linear motion control. Compatible with AirTAC F-HLS series cylinders, this complete assembly includes pre-installed locking nuts and protective covers to ensure operational stability and dust resistance. Enables ±2mm stroke modification range with 0.1mm precision increments, ideal for repetitive positioning applications requiring micron-level accuracy in industrial automation scenarios.
Installation guidelines:
Apply thread-locking compound (medium strength) before final tightening.
Use 8mm hex wrench for adjustment. Re-lubricate every 2,000km of cumulative
cylinder travel. Avoid overtightening beyond 1.2N·m to prevent thread deformation.
AirTAC F-HLS-A Series Stroke Adjustment Screw Kit Specifications
- Model: F-HLS12A
- Type: Front/Rear Mounted Stroke Adjustment Kit
- Material: Stainless Steel (SUS303) & Aluminum Alloy
- Stroke Adjustment Range: ±2mm (standard)
- Screw Pitch: M6×1.0
- Applicable Cylinder Series: HSC, HSD, HSU (φ12mm bore)
- Installation Torque: 0.49-0.98N·m
- Temperature Range: -20℃ to 80℃
- Surface Treatment: Black Oxide (screws), Anodized (brackets)
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 19mm(W) × 12.5mm(H)
- Lock Nut: M6 Brass
- Thread Engagement: 8mm minimum
Precision-engineered stroke limiter kit featuring dual-axis adjustment capability for fine-tuning cylinder end positions. Includes pre-assembled components with anti-vibration lock nuts and wear-resistant contact surfaces. Compatible with ISO 6432 standard cylinders.
Typical Applications:
- Position calibration in automated assembly lines
- End-of-arm tooling adjustment for robotic manipulators
- Precision stopping mechanisms in packaging machinery
- Overstroke prevention in press equipment
- Position fine-tuning for CNC machine fixtures
Installation guidelines:
Apply thread-locking compound (medium strength) before final tightening.
Use 8mm hex wrench for adjustment. Re-lubricate every 2,000km of cumulative
cylinder travel. Avoid overtightening beyond 1.2N·m to prevent thread deformation.
| Property | Property Value |
|---|---|
| sku | F-HLS12A |
| Bore Diameter | 12mm |
