This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ASE100X15 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ASE100X15 in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ASP Single Acting Guided Compact Cylinder ASP100X15
The AirTAC Airtac ASP Single Acting Guided Compact Cylinder ASP100X15 is a single acting, push (spring return) DIN-standard tight/compact air cylinder with a Ø100mm bore and 15mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ASE100X15 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke15 mm
- Port size1/4"
- Acting typeSingle acting, push (spring return)
- Rod threadM16×1.5
- StatusDiscontinued → ASE100X15
About the Airtac ASP Single Acting Guided Compact Cylinder ASP100X15
A single acting push cylinder with spring return, the ASP100X15 uses shop air to extend its 25 mm rod and an internal spring to retract it, so one air line is all the plumbing takes. At the big 100 mm bore it delivers 3640.7 N of push at 0.5 MPa (5211.5 N at 0.7 MPa), already net of the spring, and it runs on 0.2-1.0 MPa (28-145 psi) with a 1/4" port and a female M16x1.5 rod thread.
The short ISO 21287-style body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it slots into heavy clamping fixtures and press heads where a full-length body cannot. In practice, plan on about 2184 N of usable work at 0.5 MPa, which lifts roughly 185 kg vertically with a 2:1 margin. Note this model is discontinued: the current-production drop-in is the ASE100X15, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ASP Single Acting Guided Compact Cylinder ASP100X15 Technical Specifications
| Model | Airtac ASP Single Acting Guided Compact Cylinder ASP100X15 |
|---|---|
| Series | ASP DIN compact cylinder (discontinued) |
| Replacement | ASE100X15 |
| Bore size | Ø100 mm |
| Stroke | 15 mm |
| Acting type | Single acting, push (spring return) |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 25 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ASE100X15 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force (spring return) |
|---|---|
| 0.5 MPa | 3640.7 N |
| 0.7 MPa | 5211.5 N |
Single-acting push: air extends the rod; the return spring retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ASP Single Acting Guided Compact Cylinder ASP100X15
| ASP | DIN compact cylinder (single-acting push, spring-return, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ASP Single Acting Guided Compact Cylinder ASP100X15 Is Used
Bench press clamping
The 3640.7 N push at 0.5 MPa clinches steel brackets in a welding fixture, and the 15 mm stroke is enough to clear loading by hand.
Die locating on a stamping line
Spring return pulls the platen back automatically when air drops, keeping the die station clear between cycles.
Pallet gate actuation
A single air line swings a heavy material-gate arm; the fixed TPU bumpers take the end-of-travel shock at 50-500 mm/s.
Replacing the Airtac ASP Single Acting Guided Compact Cylinder ASP100X15 with the ASE100X15
Size down to an ASP63X15 (1420.5 N at 0.5 MPa) if your part weighs under about 85 kg, or stay at 100 mm when you need the full 3640.7 N. Remember the spring drives the rod home on air loss, so it will not hold a mid-stroke position. FA/FB flange or LB foot mounts bolt to the same face, and if you need end-of-stroke sensing, order the -S code to enable CMSE / DMSE switches. For new builds, specify the ASE100X15 instead.
Replacement checklist
- ✓ Current-production ACE → ASE100X15
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ASP Single Acting Guided Compact Cylinder ASP100X15 FAQ
Push is 3640.7 N at 0.5 MPa and 5211.5 N at 0.7 MPa, both already net of the return spring. It needs at least 0.2 MPa to beat the spring, runs on 0.2-1.0 MPa (28-145 psi) with 1.5 MPa (215 psi) proof pressure, moves at 50-500 mm/s, works from -20 to +70 C on air filtered to 40 um, and has a 1/4" port with a female M16x1.5 rod thread.
The ASP family is discontinued; the current-production drop-in is the ASE100X15 (swap the P for an E) in the same bore, stroke and force class. FA/FB flange and LB foot brackets bolt to the standard face, and the fixed TPU bumpers at both ends simply decelerate the rod - they never lock or hold a load. Confirm ISO 21287 mounting dimensions before swapping.
