Airtac ATQ Single Acting Thin Cylinder ATQ12X15
The AirTAC Airtac ATQ Single Acting Thin Cylinder ATQ12X15 is a genuine single-acting COMPACT (JIS) cylinder (single acting, pull type) with a Ø12mm bore and 15mm stroke. Air pulles the rod and an internal spring performs the opposite stroke, so one solenoid line drives the motion — ideal for short-stroke clamping and ejection in tight spaces.
- BoreØ12 mm
- Stroke15 mm
- Port sizeM5×0.8
- Acting typeSingle acting, pull type
- Rod threadM3×0.5 (F) / M5×0.8 (B)
- CushionBumper
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATQ Single Acting Thin Cylinder ATQ12X15
The AirTAC ATQ12X15 is a single-acting PULL-type JIS compact cylinder where supplying air to one M5x0.8 port retracts the 6mm rod, while an internal spring drives the extension stroke. It delivers a 42.4N theoretical pull at 0.5 MPa (59.4N at 0.7 MPa) before spring deduction. Because the return spring consumes some energy, always verify the exact net output force from the official datasheet for your specific load.
Designed for short-stroke tasks, this 15mm travel unit features a fixed TPU elastomer bumper absorbing end-of-stroke impact rather than an adjustable air cushion. The body includes magnetic-switch grooves, though this specific configuration ships without the internal magnet. Operating pressure begins at 0.2 MPa to overcome the spring, and the unit safely extends to its rest position if air pressure is lost.
Airtac ATQ Single Acting Thin Cylinder ATQ12X15 Technical Specifications
| Model | Airtac ATQ Single Acting Thin Cylinder ATQ12X15 |
|---|---|
| Series | ATQ JIS compact single-acting cylinder |
| Bore size | Ø12 mm |
| Stroke | 15 mm |
| Acting type | Single acting, pull type |
| Port size | M5×0.8 |
| Rod end thread | M3×0.5 female / M5×0.8 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Bumper |
| Max standard stroke | Up to 20 mm |
Specifications follow the official AirTAC ACQ-family datasheet. Single-acting types start at 0.2 MPa (the spring must be overcome). Confirm against the product label before installation.
Theoretical Output Force (Ø12mm, Pull)
| Pressure | Pull force (before spring) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
These are theoretical air-side forces; the return-spring force reduces the NET usable output. Single-acting pull only — the spring performs the opposite stroke. Confirm the net figure from the datasheet and size with a safety margin.
Model Code: Airtac ATQ Single Acting Thin Cylinder ATQ12X15
| ATQ | JIS compact single acting, pull type cylinder series. |
|---|---|
| 12 | Bore size in mm. |
| ×15 | Stroke length in mm (single-acting max 20 mm). |
| S | Built-in magnet for magnetic-switch sensing (omit = none). |
| B | Male-thread piston rod (omit = female thread). |
Thread: PT standard (G / NPT available). ASQ pushes out / spring returns; ATQ pulls in / spring extends. Related: ACQ (double acting), ACQD (double rod), ACQJ (adjustable stroke).
Where the Airtac ATQ Single Acting Thin Cylinder ATQ12X15 Is Used
Pin Extraction
Retracts a 6mm rod to withdraw a locating pin on small assembly jigs, relying on the internal spring to push the pin back out when air is removed.
Gate Retraction
Pulls a lightweight diverter gate closed across a packaging line, using the spring-extend function to safely open the passage during an air loss event.
Tension Release
Draws back a small clamping lever in textile machinery, maintaining tension during operation and automatically releasing the hold on exhaust.
Is the Airtac ATQ Single Acting Thin Cylinder ATQ12X15 the Right Cylinder?
When sizing this 12mm bore actuator, stepping up to the 16mm bore raises the 0.5 MPa theoretical pull to 75.4N, while stepping down is unavailable as 12mm is the smallest option. If your mechanism requires a travel distance beyond the 20mm maximum single-acting limit, you must switch to the double-acting ACQ series. To finalize your order, confirm the 15mm stroke, the female M3x0.5 rod-end thread, and whether you need the -S magnet option for position sensing.
Quick checklist
- ✓ Net pull force (after spring) at your pressure
- ✓ Stroke ≤ 20 mm (single-acting limit)
- ✓ Single air line saves a valve/port
- ✓ Magnet (S) for sensors?
- ✓ Female (blank) or male (B) rod thread
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Remember the spring performs the return stroke.
- check Avoid side load on the short piston rod.
- check Handle the C-clip carefully; seat it fully in its groove.
- check Installation by qualified personnel per AirTAC docs.
Airtac ATQ Single Acting Thin Cylinder ATQ12X15 FAQ
It provides a 42.4N theoretical pull at 0.5 MPa and 59.4N at 0.7 MPa before spring deduction. The maximum standard stroke for a 12mm bore is 20mm, and it requires a minimum operating pressure of 0.2 MPa. The internal spring performs the extension stroke.
If air pressure is lost, the internal spring automatically extends the rod to its resting position. End-of-stroke impact is controlled by a fixed TPU elastomer bumper, not an adjustable air cushion. Note that this model lacks the internal magnet, so reed or solid-state switches will not function without adding the -S option.
