Airtac ATQ Single Acting Thin Cylinder ATQ16X15S
The AirTAC Airtac ATQ Single Acting Thin Cylinder ATQ16X15S is a genuine single-acting COMPACT (JIS) cylinder (single acting, pull type) with a Ø16mm bore and 15mm stroke. Air pulles the rod and an internal spring performs the opposite stroke, so one solenoid line drives the motion — ideal for short-stroke clamping and ejection in tight spaces.
- BoreØ16 mm
- Stroke15 mm
- Port sizeM5×0.8
- Acting typeSingle acting, pull type
- Rod threadM4×0.7 (F) / M6×1.0 (B)
- CushionBumper
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATQ Single Acting Thin Cylinder ATQ16X15S
The AirTAC ATQ16X15S is a single-acting PULL-type JIS compact cylinder where supplying air to its single M5x0.8 port retracts the 8mm rod. Once exhaust occurs, an internal mechanical spring drives the piston back out. This fail-safe extend behavior makes the unit inherently suited for hold-down release and tensioning tasks.
Operating within a 0.2-1.0 MPa range, this 16mm bore actuator yields a 75.4 N theoretical pull at 0.5 MPa (105.6 N at 0.7 MPa) before spring deduction. Because the return mechanism consumes energy, the actual net output is lower and requires datasheet confirmation. The 15mm travel stays well under the 20mm single-acting limit, and the body incorporates a fixed TPU elastomer bumper rather than adjustable air cushions.
Airtac ATQ Single Acting Thin Cylinder ATQ16X15S Technical Specifications
| Model | Airtac ATQ Single Acting Thin Cylinder ATQ16X15S |
|---|---|
| Series | ATQ JIS compact single-acting cylinder |
| Bore size | Ø16 mm |
| Stroke | 15 mm |
| Acting type | Single acting, pull type |
| Port size | M5×0.8 |
| Rod end thread | M4×0.7 female / M6×1.0 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Bumper |
| Max standard stroke | Up to 20 mm |
Specifications follow the official AirTAC ACQ-family datasheet. Single-acting types start at 0.2 MPa (the spring must be overcome). Confirm against the product label before installation.
Theoretical Output Force (Ø16mm, Pull)
| Pressure | Pull force (before spring) |
|---|---|
| 0.5 MPa | 75 N |
| 0.7 MPa | 106 N |
These are theoretical air-side forces; the return-spring force reduces the NET usable output. Single-acting pull only — the spring performs the opposite stroke. Confirm the net figure from the datasheet and size with a safety margin.
Model Code: Airtac ATQ Single Acting Thin Cylinder ATQ16X15S
| ATQ | JIS compact single acting, pull type cylinder series. |
|---|---|
| 16 | Bore size in mm. |
| ×15 | Stroke length in mm (single-acting max 20 mm). |
| S | Built-in magnet for magnetic-switch sensing (omit = none). |
| B | Male-thread piston rod (omit = female thread). |
Thread: PT standard (G / NPT available). ASQ pushes out / spring returns; ATQ pulls in / spring extends. Related: ACQ (double acting), ACQD (double rod), ACQJ (adjustable stroke).
Where the Airtac ATQ Single Acting Thin Cylinder ATQ16X15S Is Used
Pin Extraction
Retracts a locating pin on automated machining centers to release finished components after a clamping cycle.
Gate Retraction
Pulls a diverter gate out of the product flow path on packaging lines when air pressure is applied.
Tension Release
Draws back a tensioning jaw on textile machinery, relying on the spring to safely extend and slacken the material.
Is the Airtac ATQ Single Acting Thin Cylinder ATQ16X15S the Right Cylinder?
When sizing this 16mm bore, dropping down to a 12mm version reduces the theoretical pull to 42.4 N at 0.5 MPa, whereas stepping up to a 20mm bore raises it to 117.8 N. If your mechanism requires a stroke exceeding 20mm, you must switch to the double-acting ACQ series. To finalize your ATQ16X15S order, verify the 15mm stroke, confirm the -S magnet for sensing, and note the standard female M4x0.7 rod-end thread.
Quick checklist
- ✓ Net pull force (after spring) at your pressure
- ✓ Stroke ≤ 20 mm (single-acting limit)
- ✓ Single air line saves a valve/port
- ✓ Magnet (S) for sensors?
- ✓ Female (blank) or male (B) rod thread
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Remember the spring performs the return stroke.
- check Avoid side load on the short piston rod.
- check Handle the C-clip carefully; seat it fully in its groove.
- check Installation by qualified personnel per AirTAC docs.
Airtac ATQ Single Acting Thin Cylinder ATQ16X15S FAQ
It provides a 75.4 N theoretical pull at 0.5 MPa and 105.6 N at 0.7 MPa before spring deduction. The internal spring lowers the net output, which must be confirmed from the datasheet. The maximum standard stroke for this 16mm bore is 20mm, and it requires a minimum 0.2 MPa operating pressure to overcome the spring.
If air pressure is lost, the internal spring automatically extends the rod to its resting position. Deceleration at the end of travel is handled by a fixed TPU elastomer bumper, not an adjustable air cushion. The included -S magnet allows position detection using either reed or electronic solid-state switches.
