Airtac GAF Filter GAF20006JW
The AirTAC Airtac GAF Filter GAF20006JW is a genuine compressed-air filter. Its diversion structure spins the air to separate liquid water and trap solid particles down to 5 µm, protecting downstream valves and tools. It has 1/8" ports and a 25 cc drain bowl. It is a filter only — it does not regulate or set pressure.
- TypeAir filter
- Port size1/8"
- Filtering grade5 µm
- Pressure range0.15 - 0.9 MPa
- Bowl materialPC
- Drainsemi-auto + manual
- Drain bowl25 cc
- Weight200 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAF Filter GAF20006JW
The GAF20006JW is a genuine AirTAC air filter that spins incoming air to throw liquid water and solid particles into its 25 cc drain bowl, while the 5 um HDPE core traps fine grain. It is a filter only, with no regulator, no pressure gauge and no lubricator, so it cleans the air but never sets or holds pressure.
This compact 1/8in unit weighs just 200 g and is rated for 0.15-0.9 MPa (20-130 psi) working pressure with a proof of 1.5 MPa (215 psi). The 5 um element suits precision valves or instrument air, and the clear PC bowl lets you see condensate levels at a glance.
Airtac GAF Filter GAF20006JW Technical Specifications
| Model | Airtac GAF Filter GAF20006JW |
|---|---|
| Series | GAF200 air filter |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Bracket | Not included (J) |
| Fluid | Air |
|---|---|
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Element | HDPE filter core |
| Weight | 200 g |
Specifications follow the official AirTAC GAF catalogue (pages 225-226). Air must not freeze in the unit. This is a filter only — it separates water and solid particles but does not set or hold a downstream pressure. To regulate pressure as well, use the matching GAFR200 filter-regulator.
Model Code: Airtac GAF Filter GAF20006JW
| GAF200 | GA200 series air filter — sets the port range, drain-bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| J | No bracket (J) — supplied without the mounting bracket. |
| W | Filtering grade 5 µm. |
| (blank) | PT port thread. |
A GAF has no regulator and no pressure gauge — there is no type, gauge or reflux code. Need to regulate pressure too? The matching GAFR200-06 is the same filter with a built-in regulator.
Size Class & Flow Envelope
- GAF2001/8"-1/4" · 3000 L/min
- GAF3001/4"-1/2" · 6000 L/min
- GAF4003/8"-1/2" · 8000 L/min
- GAF5003/4" · 9000 L/min
- GAF6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. A filter this size drops less pressure at flow than the same-body GAFR filter-regulator, so match it to your peak demand.
| This model | GAF200 · 1/8" · curve to 3000 L/min |
|---|---|
| One size up | GAF300 (curve to 6000 L/min) |
| Add regulation | GAFR200-06 (filter + regulator) |
Where the Airtac GAF Filter GAF20006JW Is Used
Protect a Precision Jig
Mount this 1/8in filter directly upstream of a small pneumatic jig or fixture. The 5 um element keeps fine abrasive dust from scoring precision locating pins and bushings.
Guard a Single Air Tool
Fit the GAF20006JW on the supply line to one air tool, such as a small die grinder or nailer. The 25 cc bowl is easy to check and drain between shifts.
Clean Air for a Test Rig
Use this filter on a laboratory or test bench air supply where a compact footprint matters. The 5 um element helps protect sensitive flow meters and pressure transducers from particle contamination.
Is the Airtac GAF Filter GAF20006JW the Right Filter?
Choose the GAF200 body when your line is 1/8in or 1/4in and you need a compact, lightweight filter for a single valve or small jig. The 5 um element traps far finer particles than the standard 40 um, which is ideal for precision equipment but requires more frequent element service. This model ships without the mounting bracket (J), so plan for a panel mount or use an existing bracket, and the PT thread standard must match your fittings. The semi-auto and manual drains are both fitted, giving you automatic condensate release plus a manual backup for service. If you also need a set pressure, use the matching GAFR200-06 filter-regulator instead, because this GAF does not regulate. With a 25 cc bowl versus the GAF300's 60 cc, the GAF200 needs roughly 2.4x more frequent draining for the same condensate load.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Element 40 µm (general) or 5 µm (fine)
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Bracket kept or removed (J)
- ✓ Need pressure control too? Use GAFR200
Installation & Maintenance Notes
- check Install with the airflow arrow: IN to OUT, bowl accessible.
- check Place the filter FIRST in the air-prep train, ahead of any regulator or lubricator.
- check Keep pressure at or below the 1.5 MPa (215 psi) proof limit.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 200 g unit on its bracket, not on the tubing.
This is a filter only — it removes water and solid particles but adds no pressure control and no lubrication. Add a GAR regulator, a GAL lubricator, or step up to the GAFR200-06 filter-regulator as your air-prep needs grow.
Airtac GAF Filter GAF20006JW FAQ
The GAF20006JW is a 1/8in PT-thread air filter with a 5 um HDPE element. It has a 25 cc drain bowl and weighs 200 g. The working pressure range is 0.15-0.9 MPa (20-130 psi), proof pressure is 1.5 MPa (215 psi), and the temperature range is -5 to 70 C. The flow curve is plotted to 3000 L/min.
The J code means the mounting bracket is not included. You can mount the GAF20006JW directly to a panel using the body's mounting holes, or use an existing bracket from a previous filter. The unit weighs only 200 g, so it does not need heavy structural support, but it should not be supported by the tubing alone.
