Airtac GAR Air Regulator GAR20006LJ
The AirTAC Airtac GAR Air Regulator GAR20006LJ is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.4 MPa range, with 1/8" ports and a built-in circular pressure gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/8"
- Pressure range0.05 - 0.4 MPa
- RegulationLower pressure
- GaugeCircular
- Reflux valveNo
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20006LJ
The GAR20006LJ is an air pressure regulator that takes a higher supply and holds a steady, lower downstream pressure you set with the knob. It regulates pressure only - it does not filter, clean, or dry the air, and has no drain bowl or filter element. This unit has a 1/8" port and weighs 170 g, placing it in the compact GAR200 size class.
This lower-pressure (L) model regulates from 0.05 to 0.4 MPa (7-58 psi), giving finer resolution over that low band than a standard unit. The pressed-in self-locking knob prevents the setpoint from drifting due to vibration or accidental knocks, while the balanced adjustment mechanism holds the setting as supply pressure varies. A circular gauge with clip and magnifier is fitted, reading MPa/psi, and saves panel space.
Airtac GAR Air Regulator GAR20006LJ Technical Specifications
| Model | Airtac GAR Air Regulator GAR20006LJ |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/8" (PT thread) |
| Regulation type | Lower pressure |
| Pressure range | 0.05 - 0.4 MPa (7 - 58 psi) |
| Pressure gauge | Circular, MPa / psi scale |
| Bracket | Not included (J) |
| Reflux valve | None |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20006LJ
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| L | Lower pressure regulation: 0.05 - 0.4 MPa (7 - 58 psi). This body offers S (standard) or L (lower pressure). |
| J | No bracket (J) — panel mount or existing bracket. |
| (blank) | Circular pressure gauge fitted. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow (reflux) valve. |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-06 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/8" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-06 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20006LJ Is Used
Low-pressure clamping
Set a gentle, repeatable clamp force on a small fixture or work-holder where a standard 0.9 MPa regulator would apply too much force. The L type's finer low-band resolution lets you dial in a precise 0.1-0.3 MPa holding pressure.
Lab air supply
Feed a sensitive laboratory instrument or pneumatic control circuit that needs a stable, low-pressure air supply. The balanced design holds the setpoint steady even if the plant supply pressure fluctuates.
Single tool pressure
Protect a small air tool or a single cylinder from supply swings by regulating its pressure down to a safe, low level. The self-locking knob keeps the setting fixed during operation.
Is the Airtac GAR Air Regulator GAR20006LJ the Right Regulator?
Choose the GAR20006LJ when you need a compact regulator for a 1/8" line and a low pressure setpoint below 0.4 MPa. The L type is ideal for delicate low-pressure tasks but cannot reach a 0.5-0.6 MPa setpoint, so for standard machine pressures select the S type instead. This model comes without a mounting bracket (J), so plan for panel mounting or use an existing bracket. The circular gauge is fitted and reads MPa/psi on the PT thread. If your line also needs clean air, use a GAFR200-06 filter-regulator or a separate GAF filter upstream. The standard S type spans about 2.4x this L type's adjustable band (0.85 MPa vs 0.35 MPa).
Quick checklist
- ✓ Body size for your air demand (1/8" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-06 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20006LJ FAQ
The GAR20006LJ regulates air pressure from 0.05 to 0.4 MPa (7-58 psi). Maximum supply pressure is 1.0 MPa (145 psi), and proof pressure is 1.5 MPa (215 psi). Operating temperature range is -20 to 70 C. The unit weighs 170 g and has a 1/8" port. It is a regulator only - it does not filter or clean the air.
The L indicates a lower-pressure regulator, with a range of 0.05-0.4 MPa instead of the standard 0.05-0.9 MPa. This gives finer adjustment in the low band but cannot reach higher setpoints. The J suffix means no mounting bracket is included, so you must mount it on a panel or use an existing bracket.
