Airtac GAR Air Regulator GAR20006LK
2. Press-in self-locking mechanism prevents preset pressure deviation caused by external vibration or interference;
3. Balanced-design pressure adjustment mechanism ensures stable regulation with minimal pressure drift and excellent pressure characteristics;
4. Supports both panel mounting and optional fixed bracket installation configurations;
5. Available in standard version and low-pressure variant (maximum adjustable pressure: 0.4MPa).
Category: Pressure Regulator | Brand: AirTAC | Series: GAR
AirTAC GAR20006LK Precision Pressure Regulator Specifications
- Model: GAR20006LK
- Type: Diaphragm-operated pressure regulator with gauge port
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Max inlet pressure: 1.0 MPa
- Pressure gauge range: 0–1.6 MPa (standard dial type)
- Adjustment knob rotation: 270°±5°
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (nitrile rubber)
- Temperature range: -5℃ to 80℃ (no freezing)
- Flow rate: 1,200 NL/min (at 0.7 MPa)
- Weight: 580g ±3%
- Dimensions: 100mm(L) × 50mm(W) × 80mm(H)
- Mounting orientation: Vertical (±15° tolerance)
- Vibration resistance: ≤1.5mm amplitude at 10–55Hz
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. Includes a locking ring mechanism to prevent accidental adjustment drift. The integrated 40mm diameter gauge enables real-time monitoring, with anti-vibration liquid filling for needle stability. Designed for systems requiring precise air pressure maintenance.
- Pneumatic conveyor line pressure stabilization
- CNC machine tool air circuit control
- Automated assembly station tooling
- Plastic injection molding machine air systems
- Semiconductor manufacturing equipment
Installation protocol:
Always install downstream filter (5μm or finer) before regulator.
For horizontal piping, orient drain port downward. Lubricate adjustment
thread monthly with ISO VG32 hydraulic oil. Maximum tightening torque
for gauge port: 4.5N·m.
| Property | Property Value |
|---|---|
| sku | GAR20006LK |
| Port Size | PT1/8 |
