Airtac GAR Air Regulator GAR20006LNK
The AirTAC Airtac GAR Air Regulator GAR20006LNK is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.4 MPa range, with 1/8" ports and a no-gauge (N) port for a panel gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/8"
- Pressure range0.05 - 0.4 MPa
- RegulationLower pressure
- GaugeNone (N)
- Reflux valveYes (K)
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20006LNK
The GAR20006LNK is an AirTAC air pressure regulator that takes a higher supply pressure and holds a steady lower downstream pressure you set with the knob. It is a regulator only - it does not filter the air, remove water, or separate particles, and has no drain bowl or filter element. This unit has a 1/8" port, weighs 170 g, and is the lower-pressure type, regulating from 0.05-0.4 MPa (7-58 psi).
The pressed-in self-locking knob prevents the set pressure from drifting due to vibration or accidental knocks, so your downstream setting stays where you left it. The balanced adjustment mechanism helps the regulator hold its setpoint as the supply pressure varies. This model has no gauge fitted, so you read the pressure on the line's own panel gauge instead.
Airtac GAR Air Regulator GAR20006LNK Technical Specifications
| Model | Airtac GAR Air Regulator GAR20006LNK |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/8" (PT thread) |
| Regulation type | Lower pressure |
| Pressure range | 0.05 - 0.4 MPa (7 - 58 psi) |
| Pressure gauge | None (N) — MPa / psi port |
| Bracket | Included |
| Reflux valve | Attached (K) |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20006LNK
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| L | Lower pressure regulation: 0.05 - 0.4 MPa (7 - 58 psi). This body offers S (standard) or L (lower pressure). |
| (blank) | Mounting bracket included. |
| N | No gauge (N) — for a line with a panel gauge already. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached (K). |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-06 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/8" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-06 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20006LNK Is Used
Low-pressure clamping
Set a gentle, repeatable 0.1 MPa (14.5 psi) for a delicate workpiece clamp in a light assembly fixture. The L type's finer low-band resolution keeps the force consistent without over-pressing the part.
Single air tool supply
Feed a small pneumatic screwdriver or blow gun at a stable 0.25 MPa (36 psi) from a higher shop-air supply. The self-locking knob holds the setting even with tool vibration on the bench.
Lab air bench
Provide a controlled 0.3 MPa (43.5 psi) to a test fixture or air bearing in a lab setup. The compact 170 g body mounts on a panel or bracket without straining the tubing.
Is the Airtac GAR Air Regulator GAR20006LNK the Right Regulator?
Choose the GAR20006LNK when you need a compact 1/8" port regulator for a lower-pressure circuit, such as a small clamp or a single air tool. The L type regulates only 0.05-0.4 MPa (7-58 psi), giving finer resolution over that low band, but it cannot reach a 0.5-0.6 MPa setpoint at all, so it is the wrong part for a standard machine. This model includes the mounting bracket, has no gauge (N), uses PT threads with an MPa/psi gauge scale, and has a reverse-flow (reflux) valve attached (K). If the line also needs clean air, use the matching GAFR200-06 filter-regulator or a separate GAF filter upstream, since a GAR does not clean the air. The standard S type spans about 2.4x this L type's adjustable band (0.85 MPa vs 0.35 MPa).
Quick checklist
- ✓ Body size for your air demand (1/8" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-06 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20006LNK FAQ
The GAR20006LNK is a lower-pressure air regulator with a 1/8" port. It regulates from 0.05-0.4 MPa (7-58 psi). Maximum supply pressure is 1.0 MPa (145 psi), proof pressure is 1.5 MPa (215 psi), and the temperature range is -20 to 70 C. The unit weighs 170 g and has no gauge fitted.
The 'L' means this is the lower-pressure type, regulating only 0.05-0.4 MPa (7-58 psi) instead of the standard 0.05-0.9 MPa range. The 'N' means no pressure gauge is fitted, so you read the downstream pressure on the line's own panel gauge. The 'K' indicates a reverse-flow (reflux) valve is attached.
